dormakaba Mounting instructions
1
About this manual
1.1
Information about the manual
This manual describes the installation of STUDIO
Rondo glass/glass hinges and contains information on
care and maintenance. The mounting is shown using
the example of a left-opening door. The mounting for
a right-opening door is laterally inversed.
1.2
Target group
dormakaba glass fittings may only be installed by
qualified personnel who are specially trained in
glazing installation.
1.3
Symbols used
1.3.1
Safety instructions
CAUTION
This signal word indicates a situation of
potential risk, which could lead to minor or
slight injury if not averted.
1.3.2 Further labeling
1.
2.
Step-by-step graphics
Position numbers for parts
1
2
in graphics
2
Safety
CAUTION
Risk of injury from sharp edges.
Incorrect handling during mounting can
cause the glass to break, resulting in injury.
• Read and follow the safety instructions in
this manual carefully.
• Make the installation site safe.
• Wear personal protective clothing.
CAUTION
Risk of crushing during installation of the
glass door panel.
During mounting, there is a risk of crushing
injuries to the fingers by the glass edges.
• Wear protective gloves.
• Use glass suction cups.
STUDIO Rondo glass/glass
2.1
STUDIO Rondo glass/glass hinges are designed for
interior Glass Doors. The hinges clamp the glass door
panel between the panel section and the counter-
plate. The hinges are only designed for dry interior
applications and pivots must be vertically aligned.
2.2
• STUDIO Rondo glass/glass hinges are not suitable
• Glass door panels must not be swung open, they
• Glass door panels must not be slammed shut.
• A device, such as a doorstop, must be installed to
2.3
• Toughened safety glass (TSG)
• In areas with additional requirements, e.g.
• Glass thickness 8 or 10 mm, depending on version.
• Maximum door panel weight 35 kg
• Do not use self-cleaning coatings.
• Textured glass surfaces or glass of heavily varying
• Do not use glass with conchoidal fractures and/or
• Installation should be free of tension (torque should
• The specified gaps must be taken into account
2.4
• dormakaba recommends fixing the side panel with
• A U-profile must be used for fixing to the floor; a
• The side panel must be level and vertically aligned.
• The side panel and supporting structure must be
WN 059480 45532
Intended use
Foreseeable misuse
for showers, sauna, bath or salt-water bath
applications or areas where chemicals (e.g. chlorine)
are used.
need to be opened by hand.
prevent the glass door panels from opening too far.
Requirements for the glass door panel
nurseries, the use of heat-soaked toughened safety
glass (TSG-H compliant with DIN EN 12150-1) is
recommended.
thickness should only be used with a corresponding
leveling layer.
damaged edges.
not be exceeded by over-tightening screws).
when aligning the glass door panel. The gaps must
be such that the glass is prevented from coming
into contact with hard materials (e. g. glass, metal,
concrete).
Requirements for the side panel
a wall connecting profile.
silicone joint is not sufficient for this purpose.
capable of bearing the weight of the glass door
panel.
About this manual
2018-09
7
