In section 10 (Charger indicator) you will fi nd a
table with an explanation of the LED indicator on
the charger.
If the battery pack fails to charge, check for the
following:
•
voltage at the power socket
•
whether there is good contact at the charging
contacts of the charging unit.
If the battery pack still fails to charge, send
•
the charger and charging adapter
•
and the battery pack
to our customer service center.
To ensure that items are properly packaged
and delivered when you send them to us,
please contact our customer service or the
point of sale at which the equipment was
purchased.
When shipping or disposing of batteries and
cordless tools, always ensure that they are
packed individually in plastic bags to prevent
short circuits and fi res.
To ensure that the battery pack provides long ser-
vice, you should take care to recharge it promptly.
You must recharge the battery pack when you
notice that the performance of the device drops.
Never allow the battery pack to become fully di-
scharged. This will cause it to develop a defect.
6.2 Changeover switch (Fig. 4/Item 3)
The slide switch above the On/Off switch is for
setting the direction of rotation of the cordless
screwdriver and for preventing the cordless
screwdriver from being switched on inadvertently.
You can select between clockwise and counter-
clockwise rotation. To avoid causing damage to
the gearing, the direction of rotation must only be
changed when the equipment is at a standstill.
When the slide switch is in the middle position,
the On/Off switch is blocked.
6.3 On/Off switch (Fig. 4 / Item 4)
Infi nitely variable speed control is possible with
the On/Off switch. The further you push the
switch, the higher the speed of the cordless
screwdriver.
To switch on:
Press the On/Off switch (4).
To switch off :
Release the ON/OFF switch (4)
Anl_TE_CI_18_1_Li_SPK9.indb 19 Anl_TE_CI_18_1_Li_SPK9.indb 19
GB
6.4 Battery capacity indicator (Fig. 5 – Item 2)
Press the battery capacity indicator switch (a).
The battery capacity indicator (2) shows the char-
ge status of the battery using 3 LEDs.
All 3 LEDs are lit:
The battery is fully charged.
2 or 1 LED(s) are lit:
The battery has an adequate remaining charge.
1 LED blinks:
The battery is empty, recharge the battery.
All LEDs blink:
The battery temperature is too low. Remove the
battery from the equipment, keep it at room tem-
perature for one day. If the fault reoccurs, this me-
ans that the rechargeable battery has undergone
exhaustive discharge and is defective. Remove
the battery from the equipment. Never use or
charge a defective battery.
6.5 LED lamp (Fig. 6/Item 7)
The LED lamp (7) can be used in poor lighting
conditions to illuminate the area where you want
to screw. The LED light (7) will come on automati-
cally as soon as you press the On/Off switch (4).
6.6 Changing the bit (Fig. 7)
Important! Set the changeover switch (3) to its
center position whenever you carry out any work
(for example changing the tool, maintenance
work, etc.) on the cordless screwdriver.
Inserting the bit:
•
Insert the bit into the bit mount (1) as far as
the stop while simultaneously pulling the slee-
ve on the bit mount (1) toward the bit.
•
Release the sleeve again.
•
Check that the bit is securely seated.
Removing the bit:
•
Pull the sleeve on the bit mount (1) toward the
bit, hold it tight and remove the bit.
6.7 Screws
It is advisable to use self-centering screws (e.g.
cross recessed head) as these will enable you to
work safely and reliably. Always make sure that
the bit used is of the same size and shape as the
screw.
