Internal connectors and slots
D3011
Intel-LAN
LAN, USB
Port 8+7
USB Port
9+10
USB Port
11+12
VGA
COM1
PS2
Audio
External connectors rear
USB dual channel
1 = VCC AUX
2 = VCC AUX
1
3 = Data negative Port X
2
4 = Data negative Port Y
5 =
All manuals and user guides at all-guides.com
PCIe4
USB 4 + 3
Battery
ICH10
USB 1+2
Super
I/O
Audio
Frontpanel
6 = Data positive Port Y
7 =
8 = GND
9 = Key
Data positive Port X 10 = Not connected
PCI2
Power Supply
FAN Control
PCI11
Power Supply 1
PCIe16
FAN1
TPM
CPU
LGA775
GMCH
Channel A
Channel B
Front panel
Power On/Off
Reset
1) Both connector positions possible
2) 2pin or 3pin connector possible
Recovery inserted = The system starts
GND
from floppy and allows a BIOS recovery
Frontpanel
Power Supply 2
FAN2
1
3
2
4
1)
Power On
2)
HD-LED
LED
Recovery
A26361-D3011-Z240-1-8N19
Fujitsu Technology Solutions
1
