UNILITE CRI-3250 Bedienungsanleitung

FEATURES
• Ultra bright 3250 lumen 30W COB LED
• High CRI 96+ coloured COB LED
• Colour temperatures from 2700k - 6500k
• Easy twist switch to change colour temperature
• Memory function - remembers last colour used
• Easy twist smooth dimming switch
• Dual power - rechargeable and mains
• 2A USB power bank for charging devices
• Super tough nylon & aluminium construction
• Built-in aluminium heat sinks
• Glow-in-the-Dark strip around reflector for extra visibility
• 170° Rotating stand with 4 strong magnets
• Adjustable head to change light angle
• IP65 dust & water resistant
• Powerful 11.1v 5200mAh li-ion batteries
• With battery level and charging indicators
• Mains multi-country charger/power lead included
BATTERY - 11.1v 5200mAh Li-ion Rechargeable Battery
WEIGHT - 1500g
DIMENSIONS - 243 x 236 x 125mm
CHARGING
1. Only use the 15V 1.5A DC charger provided otherwise damage may
occur and warranty will be void.
2. Lift the charging port cover on the bottom of the lamp.
3. Plug the DC end of the cable into the circular charge port.
4. Plug the AC/DC plug into a mains AC plug socket.
5. The battery level indicators will illuminate and flash to show
charging status.
6. Charge Time: 4 hours
THE LAMP IS DUAL POWERED SO CAN BE USED WHILE RECHARGING
AND/OR PLUGGED IN THE MAINS VIA THE CHARGER/POWER LEAD.
The lamp can also be used as a 2A Powerbank, plug the USB end of your
device charging cable into the USB port.
**Warranty void if not used with specified chargers**
www.unilite.co.uk
ANSI FL 1 Standard
MAIN FLOOD - HIGH
MAIN FLOOD - LOW
OPERATION
LEFT SWITCH - this is the ON/OFF switch. Twist to the RIGHT to turn
the lamp ON, you will feel a click. Keep twisting to increase brightness.
Twist all the way back to the LEFT until you feel it click, lamp is now OFF.
RIGHT SWITCH - this operates the colour temperature. Twist all the way
to the LEFT for warm white 2700k, twist all the way to the RIGHT for
cool white 6500k.
ON/OFF
switch
Battery & Charge
Indicators
Charge Port
& Power Bank
ADVICE & IMPORTANT INFORMATION!
LEDs will become hot when switched on; do not touch and never place face down on any
surface – risk of fire! Even once the lamp has been switched off, DO NOT place face down
as the LEDs will stay hot/warm for a while.
Do not look directly at the LEDs. Do not operate in direct sunlight or extreme temperature
conditions (below -20⁰C or above 60⁰C).
Do not use the device if there is any visible damage to the housing, LED, charge port or charger
& cord. Take care when using the charger, always check for any damage first. DO NOT exceed
15V 1.5A charger output or damage may occur to the battery. Never remove the charger from
the mains power socket with wet hands, and do not attempt to remove by pulling the cord,
always grasp the plug unit.
The rechargeable battery will reach full performance after a few complete charging and
discharging cycles.
To keep the rechargeable battery in optimum condition, it should be recharged every 3-6
months, especially if it is not being used for a long period of time. Always fully charge batteries
before storage.
Always protect batteries from heat, intense sunlight, fire, water and moisture – danger of
explosion!
If a battery is damaged, fluids can leak out. AVOID contact as this can lead to skin irritation
and/or burns. If skin contact occurs, rinse thoroughly with water. If irritation persists, seek
medical advice. Seek immediate medical assistance if lithium battery fluid comes into contact
with the eyes.
This is not a toy, children under 12 years of age should only use the product under adult
supervision.
Do not open, disassemble or attempt to modify the product; this will void the warranty and
can be dangerous. Improper use or modification is not covered under the warranty.
Take care not to let the lens come into contact with hard/sharp objects, damage/scratches to
the lenses will affect light output.
This product is water resistant to IPX5 – DO NOT SUBMERGE. If the product has been
subjected to excessive moisture/water the warranty may be void.
This product has a 1 year standard warranty (or extended to 2 years once registered online
at WWW.UNILITE.CO.UK) against manufacturing faults and defects. It does not cover normal
wear and tear, modifications, accidental damage or poor maintenance. Unilite warranties do
not cover battery leaks or the use of incorrect chargers and cables that can damage batteries.
Do not dispose of this device in normal household waste. It must be disposed of via an
authorised electrical appliance disposal centre or at your local waste disposal unit.
Please re-use or recycle packaging where possible.
Keep these instructions for future reference or for subsequent possessors.
CRI-3250
3250
60 M 2 H
Lumens
200
14 M 64 H
Lumens
CCT switch
(2700-6500k)
