UNILITE IL-275R Bedienungsanleitung

Charging Port
OPERATION
Sequence: Top Torch > Floodlight Low > Floodlight High > Off
On/Off Switch Pocket Clip
CHARGING
1. Only use a 5v micro-USB cable.
2. Lift the charging port cover on
the side of the light.
3. Plug the micro-USB end of the
cable into the charging port.
4. Plug the USB end of the cable into
a USB charging plug/port (max 1A).
5. Charge time - 1.5 hours.
6. Red LED = charging /
Green LED = Fully Charged.
**Warranty void if not used with the specified chargers**
ADVICE & IMPORTANT INFORMATION!
Do not look directly at the LED. Do not operate in direct sunlight or extreme temperature conditions (below -10⁰C or above 40⁰C). The
LED will become hot when switched on; do not touch and do not place face down on any surface – risk of fire!
Do not use the device if there is any visible damage to the housing, switch, charge port or cable. Take care when using a USB plug adaptor, check for any damage. Do not exceed 1A output or damage may occur to the battery.
The rechargeable battery will reach full performance after a few complete charging and discharging cycles.
To keep the rechargeable battery in optimum condition, it should be recharged every 3-6 months, especially if it is not being used for a long time. Always fully charge batteries before storage. Protect batteries from heat,
intense sunlight, fire, water and moisture – danger of explosion!
If a battery is damaged, fluids can leak out. AVOID contact as this can lead to skin irritation and/or burns. If skin contact occurs, rinse thoroughly with water. If irritation persists, seek medical advice.
Seek immediate medical assistance if battery fluid comes into contact with the eyes.
Children under 12 years of age should only use the product under adult supervision.
Do not open, disassemble or attempt to modify the product; this will void the warranty and can be dangerous. Improper use or modification is not covered under the warranty.
Take care not to let the lens come into contact with hard/sharp objects, damage to the lens will affect light output.
If the product has been subjected to excessive moisture/water the warranty may be void.
Do not dispose of this device in normal household waste. It must be disposed of via an authorised disposal centre or at your local waste disposal unit.
Please re-use or recycle packaging where possible.
Keep these instructions for future reference or for subsequent possessors.
WWW.UNILITE.CO.UK
Rubber Hand Grip
COB Floodlight
Slim Head
Top Torch
Magnetic
Ball Joint
Charging Port Charging Port
Charging Indicator Charging Indicator
Red = Chargin Red = Charging
Green = Fully Green = Fully Charged
ANSI FL 1 Standard
FLOOD LIGHT - HIGH
FLOOD LIGHT - LOW
TORCH - HIGH
FEATURES
• High power 275 lumen cool white COB LED
• Additional 150 lumen cool white SMD LED top torch
• Super tough construction - IK07 shock resistant
• Durable rubber hand grip
• Rear stainless steel pocket clip attachment
• 360-degree swivel ball joint base
• Super strong magnetic base
• Easy press rear switch
• USB rechargeable - 1m micro-USB cable included
BATTERY - 3.7v 700mAh Li-polymer Rechargeable Battery
WEIGHT - 76g
DIMENSIONS - 172 x 26.5 x 25 mm
Rubber Hand Grip
Charging Port
Slim Head
On/Off Switch Pocket Clip
IL-275R
275
21 M 1½ H
Lumens
175
16 M 4 H
Lumens
150
34 M 3 H
Lumens
ON/OFF Switch
360° Rotating
Magnetic Ball Joint
COB Floodlight
Top Torch
Magnetic
Ball Joint
