FLSUN SR Benutzerhandbuch Seite 8

7. Install the other two
axes in the same way
10. Push the bottom
shell down to the
correct position
13. Move the touch
screen bracket to
one-third of the
distance from the
top shell
8. Install the bottom shell. The two
logos marked in the photo should
be facing the same direction
11. Install the
screws for each axis
in order from 1 to 4
14. Rotate the knob
clockwise to fix the
touch screen bracket
9. The top shell
should be installed
in the guide rail
12. Slide the touch
screen bracket
nut into the guide
groove of the left
axis
15. Rotate the printer
180 degrees the logo
is facing the front
