SPECIFICATIONS SPECIFICATIONS
SPECIFICATIONS SPECIFICATIONS
General Specifications General Specifications General Specifications General Specifications amended by 93/68/EEC (CE Marking). However,
electrical noise or intense electromagnetic fields
Display: 4 1/2 digit LCD, 19999 counts,
in the vicinity of the equipment may disturb the
0.7" (17.8mm) high numerals, unit
measurement circuit. Measuring instruments will
annunciators and function symbols
also respond to unwanted signals that may be
Polarity Indication: Automatic, positive
present within the measurement circuit. Users
implied, negative indicated
should exercise care and take appropriate
Zero Adjustment: Automatic
precautions to avoid misleading results when
Overrange Indication: "1 "
making measurements in the presence of
Low Battery Indication: .
+ -
electronic interference.
Change battery immediately.
Display Update Rate: 2/sec, nominal
Electrical Specifications Electrical Specifications Electrical Specifications Electrical Specifications
Operating Temperature: 0°C to 50°C, 0
Accuracies at 23°C ± 5°C, < 75% RH.
to 70% Relative Humidity
Storage Temperature: -20°C to 60°C, 0 to
DC Volts DC Volts
DC Volts DC Volts
80% RH with battery removed.
Ranges; 200mV, 2, 20, 200, 1000V
Environment: Indoor use, Altitude up to
Accuracy, all rgs: : ± (0.05% rdg +3 dgt)
2000m
Resolution, 200mV Range: 10µV
Temperature coefficient: 0.1 x (spec.
Input Impedance: 10MΩ
accur.) per °C (0-18°C, 28-50°C)
NMMR (50-60Hz): >55dB
Power: Standard 9-volt battery, NEDA 1604,
CMRR (up to 1000VDC: >110dB
JIS 006P, IEC 6F22
OL Protection, 200mV Range: 350VAC
Auto Power Off: 50 minutes after no function
or range change
Battery Life (Typical): 300 hrs alkaline
Dimensions (H x W x D): 18.3 x 7.9 x
AC Volts AC Volts - - - - True RMS AC Volts AC Volts
3.8 cm, (7.2 x 3.1 x 1.5 inches)
Ranges: 200mV, 2, 20, 200, 750V
Weight (including battery): 311 grams (11
Accuracy,50- 500Hz*:
ounces)
Accessories: Test leads, 0.5A / 250V spare
fuse, battery, operator's manual.
Accuracy, 500Hz -2kHz*:
Safety: Meets EN61010-1 Cat II-1000V;
Pollution degree 2; Class II.
EMC: Meets EN50081-1, EN50082-2
10% of range
This product complies with
Resolution, 200mV Range: 10µV
requirements of the following
Conversion: AC coupled, True RMS
European Community
Directives: 89/336/EEC (Electromagnetic
Crest Factor for True RMS: 5 : 1
Compatibility) and 73/23/EEC (Low Voltage) as
- 18 -
All manuals and user guides at all-guides.com
RMS/ 500VDC (15 seconds)
Other Ranges: 750V RMS/1000VDC
True RMS True RMS True RMS
200mV-200V rgs: ± (1.0% rdg + 10 dgt)
750V range: ± (2.0% rdg + 20 dgt)
200mV-200V rgs: ± (2.0% rdg + 20 dgt)
* In the 200mV range accuracy is for >
responding
