All manuals and user guides at all-guides.com Manual / Bedienungsanleitung Proline Series Please read this manual carefully prior to product operation! Bitte lesen Sie diese Bedienungsanleitung vor Inbetriebnahme des Produkts! English Deutsch 09/2013...
Seite 2
This manual and its information have been dem Einzelfall dokumentiert. made with due care. Laserworld AG cannot, Diese Betriebsanleitung und die darin ent- however, take any responsibility for errata, haltenen Informationen wurden mit der ge- bugs, or the resulting damages.
All manuals and user guides at all-guides.com Manual: Laserworld Proline Series Content: Scope of delivery & details Preliminary warning notices Initial operations, safety instructions Working on the device Service notes Warnings and other notices on the device Device connections Operation...
All manuals and user guides at all-guides.com Manual: Laserworld Proline Series 1. Scope of delivery & details Please check if all listed parts are included and undamaged. Included in delivery: 1 x laser projector 1 x Interlock adapter 1 x power cable...
All manuals and user guides at all-guides.com Manual: Laserworld Proline Series 13. Ensure that device does not get over- 11. Never use dimmer, RC or other electroni- heated. Make sure that the device is not cally switched sockets. Whenever possib-...
All manuals and user guides at all-guides.com Manual: Laserworld Proline Series • Removal of the warranty label as well as damages to the device caused by improper handling, neglect of the sa- fety instructions and service notes will void the warranty.
All manuals and user guides at all-guides.com Manual: Laserworld Proline Series 7. Device connections Front side laser outlet micro micro LED power LED Rear side loop for safety cord Interlock power key switch connection DMX in switch DMX out ILDA in...
All manuals and user guides at all-guides.com Manual: Laserworld Proline Series 8. Operation Connect the power cable to the device and then to the mains Insert key and turn it ‚ON‘ Press „ON“ to switch the device on Please make sure, that the Interlock adapter is inserted.
Seite 9
All manuals and user guides at all-guides.com Manual: Laserworld Proline Series Channel Value Function 1 - modes 0-63 Sound mode (only in conjunction with Channel 2) 64-127 automatic mode (only in conjunction with Channel 2) 128-191 manual sound mode (only in conjunction with Channel 2 + 3)
Seite 10
All manuals and user guides at all-guides.com Manual: Laserworld Proline Series Channel Value Function 10 - zoom 0 - 85 positive automatic zoom with increasing speed 86 - 170 negative automatic zoom with increasing speed 171 - 255 positive / negative automatic zoom with incre-...
We cannot inform you in case of changes of this manual. If you have any questions, please contact your dealer. For service please contact your dealer or Laserworld. Please use only spare parts of Laserworld. Subject to change without notice. Because of the vast amount of data we cannot guarantee any correctness of given information.
Seite 12
All manuals and user guides at all-guides.com Manual: Laserworld Proline Series Inhaltverzeichnis: Lieferumfang & Hinweise Einleitende Warnhinweise Schritte zur Inbetriebnahme, Sicherheitshinweise Sicherheitshinweise für Arbeiten am Gerät Pflege- und Wartungshinweise Warnhinweise und Spezifikationen am Gerät Geräteanschlüsse & Bedienelemente Bedienung Abschließende Erklärung...
All manuals and user guides at all-guides.com Manual: Laserworld Proline Series 1. Lieferumfang & Hinweise Bitte prüfen Sie, ob Sie die Lieferung vollständig erhalten haben und die Ware unbeschädigt ist. Im Lieferumfang enthalten sind: 1 x Laserprojektor 1 x Interlock Adapter 1 x Kaltgerätekabel zur Stromversorgung...
All manuals and user guides at all-guides.com Manual: Laserworld Proline Series 9. Bei einer Festinstallation an Wand, Decke Steckdosen! Falls möglich benutzen Sie o.ä., sichern Sie den Laser zusätzllich mit den Laser nicht zusammen mit anderen einem Sicherheitsfangseil. Das Fangseil großen elektrischen Verbrauchern (ins-...
Seite 15
Halten Sie das Gerät trocken und • Die Geräte der Ecoline, Evolution, Club schützen Sie es vor Nässe, Regen und und Proline-Serie sind nicht für professio- Spritzwasser. nellen Einsatz konzipiert. Sie sollten nach etwa einer Stunde Betrieb für ca. 15 Mi- •...
All manuals and user guides at all-guides.com Manual: Laserworld Proline Series 8. Bedienung Zunächst das Stromkabel mit dem Gerät und anschließend mit der Stromversorgung verbinden Den Schlüssel in den Schlüsselschalter stecken und auf „ON“ drehen. Durch Drücken des An- / Ausschalters auf „ON“ wird das Gerät eingeschaltet Das Gerät befindet sich im Automatik-Modus:...
Seite 18
All manuals and user guides at all-guides.com Manual: Laserworld Proline Series Kanal Wert Funktion 1 - Modus 0-63 Musikmodus (nur in Verbindung mit Kanal 2 nutzbar) 64-127 Automatikmodus (nur in Verbindung mit Kanal 2 nutzbar) 128-191 manueller Musikmodus (nur in Verbindung mit Kanal 2 nutzbar)
Seite 19
All manuals and user guides at all-guides.com Manual: Laserworld Proline Series Kanal Wert Funktion 9 - Kreisbewegung 0 - 127 manuelle Rotation 128 - 191 automatische Rotation im Uhrzeigersinn mit zunehmen- der Geschwindigkeit 192 - 255 automatische Rotation gegen den Uhrzeigersinn mit...
Seite 20
All manuals and user guides at all-guides.com Manual: Laserworld Proline Series ILDA Ansteuerung: Das Gerät („ILDA IN“) über ILDA Kabel mit einem Interface / Controller verbinden. Die Ansteuerung erfolgt anschließend über Lasersteuersoftware, wie z.B. von Phoenix oder Pangolin. Der Anschluss „ILDA OUT“ dient dazu, das Gerät mit einem weiteren zu verbinden.
Sollten Änderungen an dieser Bedienungsanleitung vorgenommen werden, können wir Sie darüber nicht in Kenntnis setzen. Bitte kontaktieren Sie für Fragen Ihren Händler. Für Servicefragen wenden Sie sich bitte an Ihren Händler oder aber an Laserworld. Verwenden Sie auschließlich Laserworld-Ersatzteile. Änderungen vorbehalten. Aufgrund der Datenmenge kann keine Gewähr für die Richtigkeit der Angaben gegeben werden.
Seite 22
All manuals and user guides at all-guides.com Manual: Laserworld Proline Series Technical data / Technische Daten / caractéristiques techniques Laser sources: DPSS (green), diode (red / blue) Laserquellen: DPSS (grün), Diode (rot / blau) Sources laser: DPSS (verde), diode (rouge / bleu)
