UNILITE WCDBL Bedienungsanleitung

FEATURES
• Super tough ABS & nylon polymer construction
• Strong magnets on the rear for securely attaching to magnetic
surfaces
• Built-in screw holes for wall mounting
• Strong magnets on the front for attaching Unilite wireless charging
lamps
• Pull-out secure phone holder for charging wireless mobile phones
• IK07 tough construction - 2m drop proof
• IP20 Dust resistant
• Built-in USB-C charging port
• Normal Charge Input: 5V-2A (only suitable for one charging location)
• Fast Charging Inputs: 12V-1.5A / 9V-2A / 5V-3A
• Quick charging 3.0 USB-C charging cable included
WEIGHT - 450g
DIMENSIONS - W 290.5 x H 101.2 x D 28.1mm
ADVICE & IMPORTANT INFORMATION!
Do not operate in direct sunlight or extreme temperature conditions (below -10⁰C or above 40⁰C).
Do not use the device if there is any visible damage to the housing or charge port. Take care
when using a USB plug adaptor and USB cables, check for any damage. DO NOT exceed the
stated charging inputs or damage may occur to the product you are charging and may void any
warranties.
Children under 12 years of age should only use the product under adult supervision.
Do not open, disassemble or attempt to modify the product; this will void the warranty and can be
dangerous. Improper use or modification is not covered under the warranty.
If the product has been subjected to water the warranty may be void.
This product has a 1 year standard warranty (or extended to 2 years once registered online at
WWW.UNILITE.CO.UK/WARRANTY) against manufacturing faults and defects. It does not cover
normal wear and tear, modifications, accidental damage or poor maintenance. Unilite warranties
do not cover the use of incorrect chargers and cables that can cause damage.
Do not dispose of this device in normal household waste. It must be disposed of via an authorised
electrical appliance disposal centre or at your local waste disposal unit.
Please re-use or recycle packaging where possible.
Keep these instructions for future reference or for subsequent possessors.
www.unilite.co.uk
CHARGING WIRELESS PRODUCTS
• Plug the USB-C end of a charging cable into the charge port on the
bottom of the charging pad.
• If using a standard USB-C cable only one item can be charged on this
double pad. To charge 2 items you will need to use the QC3.0 quick
charging cable that is included.
• Plug the USB-A end of the cable into a USB charging port (ensure you
pay attention to the max charging inputs on the back of the pad).
• Then place 1 or 2 Unilite wireless charging lamps onto the pad taking
note of the magnetic connections.
• If charging a wireless charging phone, the phone can be rested on the
left hand side of the charging pad, or if wall mounted you can pull out
the lever on the left-bottom corner to extend out the black phone holder
for secure charging. Please take note of the phone icons on the charging
pad that indicate which way to position the phone.
• The LEDs on the front of the charging pad will light up Green and
flash every 2 seconds to confirm normal charging is in process. When in
standby mode the LEDs will light up constant Green. If a strange object
is detected the LEDs will flash Red.
• Charge times will depend on the item you are charging and charging
input used.
**Warranty void if not used with the specified cables/chargers**
Strong Magnets
Wireless
Charge Connection
Screw Holes
LED
Indicators
Pull-out Lever for
Phone Holder
Phone Holder
Pull-out Lever for
Phone Holder
WCDBL
Screw Holes
Phone Holder
LED
Indicators
USB-C
Charge Port
