Technical data
TECHNICAL DATA
Part No 14124x
Turbopump TED 30/42
Motor 7,5 kW
Frequency 50 - 70 Hz
RPM 3000 - 4200
rpm
Inlet Ø 108
Max dp 23 - 18 kPa
Nominal pres- 18 - 17 kPa
sure
Max Q 450 - 650
m 3 /h
Weight 225 kg
Sound level 1 m 62 - 67 dB(A)*
Security class IP54
* With outlet and in-line silencer. With diff user outlet the sound level is 5 dB(A) higher than the given fi gure.
Air pulse fi lter cleaning
Air consumption
Hose connection
Electric connection without control box
Electric connection with control box
Main Filter, standard
Type
Part No
Total fi lter surface
Degree of separation
EN 60335-2-69 part 1
Main Filter, optional
Type PTFE coated pleated
Part No
Total fi lter surface
Degree of separation
EN 60335-2-69 part 1
All manuals and user guides at all-guides.com
4 l/s, 4 bar
6 mm
24 VAC, 19A
24 VDC, 19A
Pleated polyester
4292
2
8.4 m
> 99.9 %
429203
2
5.0 m
> 99.9 %
DC 11-Module 7.5 kW - 23
HEPA fi lter (optional 2nd fi lter )
Part No
Total fi lter surface
Degree of separation
EN 1822-1 HEPA H13
Max temp fi lter
42136
2
5.2 m
99.95%
o
80 C
Part No 94141
