unit.
• Removing the upper stainless steel cover
Remove the upper stainless steel cover of the motor unit, in which the speed
indication is integrated. To loosen the cover, use a thin slot screwdriver. Po-
sition the screwdriver in the gap between the upper cover and the plastic
housing and lever up the cover.
• Removing the main circuit board
Now the circuit board is exposed on the upper side of the motor unit.
Using a Phillips screwdriver, remove the little screws for fastening the circuit
board and lift the circuit board out of the "speed button". Using a side cutter,
for example, cut through the connection cables one after the other. Using
insulating tape, stick over the individual connections to isolate the contacts.
• Removing the accessories holder
Using a small (rubber) hammer, strike off the plastic cover of the accessories
holder below the release buttons.
• Removing the battery pack and the motor
Cautiously pull out the battery pack and motor.
Despite of complete discharge, the battery pack has a remaining capacity
which can be released in case of a short circuit.
Remove the battery pack and disconnect the connections of the battery pack
individually one by one. Using insulating tape, stick over the individual connec-
tions to isolate the contacts.
Battery packs must not be disposed of in household rubbish. Take it
to the waste collection depot intended for the purpose.

DISPOSAL OF THE UNIT

At the end of its service life, this product cannot be disposed of in
normal domestic waste. The symbol on the product and in the oper-
ating instructions point out to this fact. Reuse the materials according
to their marking. With the reuse, recycling or other forms of recycling
of old equipment, you make an important contribution to the protec-
tion of our environment. Please ask your municipal administration for the dispos-
al point.
