- Supports DVI with max. resolution up to 1920x1200 @ 60Hz
- Supports D-Sub with max. resolution up to 2048x1536 @
- Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and
- Supports HDCP function with DVI and HDMI ports
- Supports Full HD 1080p Blu-ray (BD) / HD-DVD playback
Audio - 7.1 CH HD Audio with Content Protection
- Premium Blu-ray audio support
- Supports THX TruStudio
LAN - PCIE x1 Gigabit LAN 10/100/1000 Mb/s
- Realtek RTL8111E
- Supports Wake-On-LAN
- Supports LAN Cable Detection
- Supports Energy Efficient Ethernet 802.3az
- Supports PXE
Rear Panel I/O I/O Panel
- 1 x PS/2 Keyboard Port
- 1 x D-Sub Port
- 1 x DVI-D Port
- 1 x HDMI Port
- 1 x Optical SPDIF Out Port
- 6 x Ready-to-Use USB 2.0 Ports
- 2 x Ready-to-Use USB 3.0 Ports
- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED
- HD Audio Jack: Rear Speaker/Central/Bass/Line in/Front
SATA3 - 2 x SATA3 6.0 Gb/s connectors by Intel
- 2 x SATA3 6.0 Gb/s connectors by ASMedia ASM1061,
USB3.0 - 2 x Rear USB 3.0 ports, support USB 1.0/2.0/3.0 up to
- 1 x Front USB 3.0 header (supports 2 USB 3.0 ports),
1920x1200 @ 60Hz
75Hz
HBR (High Bit Rate Audio) with HDMI (Compliant HDMI
monitor is required) (see CAUTION 7)
with DVI and HDMI ports
(Realtek ALC892 Audio Codec)
LED)
Speaker/Microphone (see CAUTION 8)
(RAID 0, RAID 1, RAID 5, RAID 10, Intel Rapid Storage and
Intel Smart Response Technology), NCQ, AHCI and Hot
Plug functions
support NCQ, AHCI and Hot Plug functions
5Gb/s
ASRock Z77 Pro4 Motherboard
TM
®
Z77, support RAID
7
