1.2 Specifications
Platform
CPU
Chipset
Memory
Expansion Slot
Graphics
6
- ATX Form Factor: 12.0-in x 7.9-in, 30.5 cm x 20.1 cm
- All Solid Capacitor design
rd nd
- Supports 3 and 2 Generation Intel
LGA1155 Package
- Digi Power Design
- 4 + 2 Power Phase Design
®
- Supports Intel Turbo Boost 2.0 Technology
®
- Supports Intel K-Series unlocked CPU
- Supports Hyper-Threading Technology (see CAUTION 1)
®
- Supports Intel Rapid Start Technology and Smart Connect
®
Technology with Intel
®
- Intel Z77
- Dual Channel DDR3 Memory Technology (see CAUTION 2)
- 4 x DDR3 DIMM slots
- Supports DDR3 2800+(OC)/2400(OC)/2133(OC)/1866(OC)/
1600/1333/1066 non-ECC, un-buffered memory
- Max. capacity of system memory: 32GB (see CAUTION 3)
®
- Supports Intel Extreme Memory Profile (XMP)1.3/1.2
- 1 x PCI Express 3.0 x16 slot (PCIE2: x16 mode)
(see CAUTION 4)
* PCIE 3.0 is only supported with Intel
®
Intel Sandy Bridge CPU, it only supports PCIE 2.0.
- 1 x PCI Express 2.0 x16 slot (PCIE3: x4 mode)
- 1 x PCI Express 2.0 x 1 slot
- 3 x PCI slots
- Supports AMD Quad CrossFireX
®
* Intel HD Graphics Built-in Visuals and the VGA outputs can
be supported only with processors which are GPU
integrated.
®
- Supports Intel HD Graphics Built-in Visuals: Intel
®
Sync Video, Intel InTru
®
Technology, Intel Insider
®
Intel Advanced Vector Extensions (AVX)
- Pixel Shader 5.0, DirectX 11 with Intel
Pixel Shader 4.1, DirectX 10.1 with Intel
- Max. shared memory 1760MB (see CAUTION 5)
- Three VGA Output options: D-Sub, DVI-D and HDMI
(see CAUTION 6)
- Supports HDMI 1.4a Technology with max. resolution up to
ASRock Z77 Pro4 Motherboard
® TM
Core
Ivy Bridge CPU
®
Ivy Bridge CPU. With
TM
and CrossFireX
TM ®
3D, Intel Clear Video HD
TM ®
, Intel HD Graphics 2500/4000,
®
Ivy Bridge CPU.
®
Sandy Bridge CPU
i7 / i5 / i3 in
TM
®
Quick
