Never reach with your hands into the machine when guiding
or sorting the workpiece.
Use a feeding aid (push wood) if you want to feed short
stock into the machine.
Thicknessing stock must have a minimum length of 160mm.
Do not thickness more than two work pieces at the same
time.
To plane stock which surfaces are not parallel, use suitable
feeding aids (make fitting templates).
Do not stand on the machine.
Connection and repair work on the electrical installation
may be carried out by a qualified electrician only.
Make all machine adjustments or maintenance with the
machine unplugged from the power source.
Have a damaged or worn cord replaced immediately.
3.3 Remaining hazards
When using the machine according to regulations some
remaining hazards may still exist
Touching the cutter block in the machining area can cause
injury. For effective protection the cutter block guard must
always be adapted to the work piece.
Risk of kickback. Work piece is caught by the rotating cutter
block and thrown back to the operator.
Drawing-in/trapping hazard by power feed mechanism.
Squeezing hazard by workpiece power-outfeed.
Thrown workpiece parts can lead to injury
Sawdust and noise can be health hazards. Be sure to wear
personal protection gear such as safety goggles and ear
protection. Use a suitable dust exhaust system.
The use of incorrect mains supply or a damaged power
cord can lead to injuries caused by electricity.
4. Machine specifications
4.1 Technical data
JPT-8B-M
Planing
Jointing width
Table length
Height above table
Fence size
Fence tilt
Depth of cut
Thicknessing
Thicknessing width
Thicknessing height
Thicknessing table length
max 200 mm
740mm
350mm
540x105mm
0 - 45°
max.3 mm
max 200 mm
5 - 120 mm
270 mm
Min. length of work piece
Feed speed
Depth of cut
Number of knives
No load speed n
o
Cuts per minute
Cutter knife length
Cutter knife thickness
Dust port diameter
Overall (LxWxH)
Net Weight
Mains
Motor power (input)
Reference current
Extension cord
Installation fuse protection
Isolation class
JPT-10B-M
Planing
Jointing width
Table length
Height above floor
Fence size
Fence tilt
Depth of cut
Thicknessing
Thicknessing width
Thicknessing height
Thicknessing table length
Min. length of work piece
Feed speed
Depth of cut
Number of knives
No load speed n
o
Cuts per minute
Cutter knife length
Cutter knife thickness
Dust port diameter Ø 64(Ø 57)mm & Ø 100mm
Overall (LxWxH)
Net Weight
Mains
Motor power (input)
Reference current
Extension cord
Installation fuse protection
Isolation class
4.2 Noise emission
(Inspection tolerance 4 dB). Work piece pinewood 100mm:
Acoustic power level (according to EN ISO 3746):
Idling
Operating
Acoustic pressure level (according to EN 11202):
Idling
Operating
160mm
6 m/min
max. 2 mm
2
9000 rpm
18000
205 mm
1.5 mm
Ø 100mm
780X440X550mm
28 kg
1~230V, PE, 50-60 Hz
1500W
6.8 A
H05W-F 3G1mm²
16A
I
max 254 mm
920mm
960mm
635x130mm
0 - 45°
max. 3 mm
max 254 mm
5 - 120 mm
305mm
160mm
6 m/min
max. 2 mm
2
9000 rpm
18000
260 mm
1.5 mm
980x470x1120mm
34 kg
1~230V, PE, 50-60 Hz
1500W
6.8 A
H05W-F 3G1mm²
16A
I
LwA 101,5 dB(A)
LwA 105,8 dB(A)
LpA 88,7 dB(A)
LpA 96,4 dB(A)
