Product Overview
AC Power
Power Linking
Fuse
Replacement
All manuals and user guides at all-guides.com
The Intimidator™ Wash LED 150 is an LED moving head light that has a
motorized focus for crisp gobo effects. Built-in effect macros and
move-in-black features minimize programming time and auto programs
generate easy shows.
Power In
Power Out
Display
This product has an auto-ranging power supply that can work with an input
voltage range of 100~240 VAC, 50/60 Hz.
You can link up to 6 Intimidator™ Wash LED 150 units at 120 VAC and 12
units at 230 VAC. You should never exceed this number.
1. Disconnect the product from power.
2. Using a flat-head screwdriver, loosen the fuse holder and pull straight
out.
3. Remove the blown fuse from the holder and replace with a fuse of the
exact same type and rating.
4. Re-insert the fuse holder and reconnect power.
Page 3 of 52
Intimidator™ Wash LED 150 QRG
Fuse Holder
DMX Out
Back Panel
Front Panel
DMX In
