Operating Hints

This chapter contains excerpts from the operating instructions. For further particulars please refer to the appropriate user instructions which can be downloaded by www.grundig.com, submenu Downloads/Manuals.
OVERVIEW
--------------------------------------------------------------------------------------------------------------
Connections on the television set
SERVICE
SERVICE
HDMI4 SATELLITE
Optic Out LAN USB3 HDMI3 (ARC) (MAIN) 13/18V max.500mA (SUB) 5 V max.50mA ANT-IN
SATELLITE ANT-IN
Optic Out LAN USB3 HDMI3 HDMI4
13/18V max.500mA 5V max.50mA
(ARC)
(MAIN) (SUB)
ENGLISH 13
OVERVIEW
--------------------------------------------------------------------------------------------------------------
SCART / S-VHS / COMPONENT
Euro/AV socket (CVBS
signal, RGB signal);
video signal input for
S-Video camera (with Scart-
S-VHS converter).
Video signal input (YUV
signal with Scart-YUV
converter).
SERVICE
Service only.
Optic Out
Audio output sockets (opti-
cal) for PCM/Dolby Digital
signals.
It is for digital multichannel
audio/video amplifier or
AV receiver connections.
LAN Network cable connection
socket.
USB 3 USB Harddisk socket for
external data medium and
PVR function;
connection for wireless
keyboard, mouse.
HDMI3 HDMI socket, audio/video
signal input (HDMI).
HDMI4 (ARC) HDMI socket, audio/video
signal input (HDMI).
SATELLITE MAIN Satellite antenna socket.
SATELLITE SUB Antenna socket for the sec-
ond satellite signal (DVB-S).
ANT IN Antenna socket.
U
Headphone connection
(3.5 mm jack);
external audio output (with
headphone-RCA con-
verter).
CI1 Common interface slot.
CI2
Common interface slot.
USB1 USB Harddisk socket for
external data medium and
PVR function;
connection for wireless
keyboard, mouse.
14 ENGLISH
USB2 USB socket for external
data medium and PVR func-
tion;
connection for wireless
keyboard, mouse.
HDMI1 (MHL)
HDMI socket, audio/video
signal input (HDMI).
HDMI2 HDMI socket, audio/video
signal input (HDMI).
