GB
– Before using the appliance, check all the components if they are properly connected
and assembled! Make sure that the contact surfaces and sealing elements are clean
and undamaged.
– As this appliance uses water to clean, the floor may remain wet and slippery for a while.
Water filling (Fig. 6, 7)
Water tank A4
When filling water, make sure that the appliance is disconnected from the mains. Turning the
lock adaptor A2, remove the container A4 from the steam unit A and pulling it out. Remove
the water tank plug A8 from the tank. Fill the tank with water or demineralised water. Do
not exceed the maximum volume of water (i.e. 380 ml). Put the plug in place. Install the
assembled tank on the steam unit A in a reverse way. Ensure that the contact surface and
the sealing elements are in order.
Water tank E2
Press the lock button, remove the water tank from the mopping nozzle E and pulling it out.
Remove the water tank plug E3 from the tank. Pour clean water (hot or cold) into water tank
or You can also add foamless detergent suitable for cleaning hard floors (i.e. 130 ml). Put
the plug in place in a reverse way. Install the assembled tank on the mopping nozzle in
a reverse way, end-to-end, which is accompanied by characteristic sound (clicking).
– Never use the appliance without the water filter A5 properly fixed.
– The steel ball of water tank A4 at the end of the hose must permanently and freely
move below the water level. If it gets stuck, free it by shaking the cleaner.
IV. STEAM CLEANER USE
First choose the appliance assembly variant, and then add/remove the respective
components and accessories of the appliance as needed. Unwind the power cord A9 from
the holder C2. Plug the power cord in a wall socket the appliance on which will be indicated
by turning on the operation light indicator (lit in red A10). The appliance is ready for cleaning
in about 25 seconds (lit in green), because the appliance does not need to heat up the entire
water tank, but it only pumps and heats a small volume of water.
To activate steam (after 30 seconds at the earliest, the operation light indicator lit in
green!), it is necessary to press the steam release button A3 (if the appliance is used as
a handheld steam cleaner), or the steam release button C1 (if the appliance is used as
a steam mop) fig. 9. The built in pump will gradually start pumping water from the tank A4,
and the appliance will start producing hot steam.
If you see a considerable decrease in steam production and low water level in the water tank
during use, water must be replenished (see "Water filling").
– After the first use or after interrupting the cleaning for several minutes, direct the
steam flow into the container to remove excessive water from the accessories (such
water is produced by the steam condensation). When steam is produced, always aim
the steam flow down at the floor.
Attention
Attention
Note
28 / 59
