Shenzhen AtomStack Technologies Co., Ltd.
3. AtomStack R3 Rotary roller installation and using
AtomStack R3 roller coordinate with either X axis or Y axis of the engraver to make the
processing, and compatible with engraver of Neje, Atomstack and Ortur. No need to adjust the
pulse, directly process after link. If coordinate with other brands, may need to adjust the pulse.
The main supplied OS is LaserGRBL and LightBurn.
Below there are software installation manual and the procedure of the pulse adjustment.
4.1 LaserGRBL installation and procedure of the pulse adjutment
1. Download the software
LaserGRBL is one of the popular software for engraving, we could visit and download from
http://lasergrbl.com/download.

2. Install LaerGRBL

Click to start the installation file, and keep clicking next step until the installation is finished.
3. LaserGRBL procedure of the pulse adjustment
*A. Start up LaserGRBL，connect the engraver and the computer which already installs
the LaserGRBL. Click the lightning mark, the connection is successful when the lightning
mark turns into red X.
4.1 LaserGRBL instal lation
4.2 LaserGRBL connecting with the laser engraver
Next
Connection/disconnect
Baud rate 115200
Com port
Lightning mark
