KWL - wiring diagram overview – easyControls
®
5 .5

Wiring diagram SS-1144

easyControls
Servomotor connection EM
15 16 17
M
24 V /
0-10 V
85438 001 SS-1144 10.06.16
Actuator for
WHSH...
24 V / 0-10V
17
15
16
10
0-10 V 2-10 V
=
- +
~
Y U
1 2 3 5
( sw)(rt)(ws ) ( ws )
