Device layout (SM-T540 / SM-T545 / SM-T547)
Volume key
Side key
(Power/Bixby)
Speaker
Proximity/
Light sensor
Touchscreen
Recents key
GPS antenna
Main antenna
(SM-T545
SM-T547)
Microphone
Earphone jack
Keyboard
dock port
Active key
Front camera
Microphone
Speaker
Multipurpose
jack
(USB Type-C)
Back key
Home key
(Fingerprint
recognition
sensor)
Rear camera
Flash
NFC antenna
Back cover
