6 Swedstyle Memory - EN
WARNING. Risk of death or serious injury in explosive atmospheres
Operating the Handset in potentially explosive atmospheres may lead to death or serious injury
through explosions.
• Read the relevant directives to determine if an atmosphere is potentially explosive
• Do not operate the Handset in potentially explosive atmospheres
CAUTION. Risk of minor or moderate injury through tripping
During the assembly process, you may have to step over Cables. Tripping over Cables may lead
to minor or moderate injury.
• Ensure that the assembly area is kept clear of unnecessary obstructions
• Be careful not to trip over Cables
CAUTION. Risk of minor or moderate injury through crushing
If any Handset Key becomes stuck while the system is in motion, the system may not stop
properly. This may lead to minor or moderate injury through crushing.
• Disconnect the system immediately if any Handset Key becomes stuck
3

THE PRODUCT

3.1 Key product features

1
Mounting points
UP/DOWN keys 2
4 Memory position keys 3
4
SAVE
Display 5

3.2 Dimensions

Length 90 mm
90
Width 120 mm
Height 26 mm
120
4

ASSEMBLY

WARNING. Risk of death or serious injury through electric shocks
Handsets are electrical devices. Basic safety precautions must be taken at all times. Failure to
observe electrical safety precautions may lead to death or serious injury through electric shocks.
• Never open the Handset
• Ensure that the Handset is not connected to the Control Box during assembly
• Do not convert or modify the Handset in any way
• Check the housing and cables of the Handset for visible damage. Do not install or operate
damaged products.
CAUTION. Risk of minor or moderate injury through improper handling
Improper handling of the product during assembly may lead to minor or moderate injury
through cutting, pinching, and crushing.
• Avoid contact with sharp edges
• Be careful while handling tools that may cause personal injury
• Ensure assembly complies with the generally accepted standards and guidelines of
electrical engineering and furniture manufacturing
• Read all instructions and safety advice carefully
Swedstyle Memory - EN
20
9
26
11
90
120
7
45°
