BEDIENUNGSANLEITUNG / INSTRUCTION MANUAL YAK 11
Now connect the servos of the pitch elevator and yaw rudder
with a servo-tester. Check the neutral position.
Secure all screw connections with Loctite.
The linkages must be hooked in fully inside at both servo-
horns.
Leave the servo-tester plugged in so that the servos remain in
the neutral position for the next construction step.
Assemble the horizontal and vertical tail as shown.
Then place the tail assemblies on the fuselage.
Now screw the tail assemblies to the fuselage.
Also screw the yaw rubber on the underside of the fuselage.
