Caliber RCD266 Schnellstartanleitung

6 2
SYSTEM
KEY
Short press
1 Mute
2 Power on/off
3
4 Audio menu
5 Mode
6 Rotary volume
7
8
9
10
11
12
13
14
15
16
17
18 Display
19
20
21
22
Panel release
Push this button to release the frontpanel
Power
Power function to activate or deactivate the unit.
Band
Band selection allows you to select different reception bands, f.i. FM1, FM2, FM3
Mute
Push this button to turn off the sound, push again to return to the last volume level.
OK
Push this button to confirm the option you have selected.
AF
AF stands for Alternative frequencies; the tuner will return to alternative frequencies whenever the reception signal is getting worse
TA
TA stands for Traffic announcement which means that it will give you information about the traffic (if broadcasted) no matter what mode
you are in (CD, USB, SD) it will automatically interrupt the music and give the information, after that it automatically switches back to the
selected mode.
PTY
The PTY function allows you to search for stations with a particular program type like NEWS group and POP group both of these groups
are divided in different subjects. PTY "POP", pop/rock, easy/light, classics/others, jazz/country, nation/oldies. PTY "NEWS", news/info,
sport/educatie, culture/science, weather/finance, social/religion
Tune up/down
Press to move the radio frequency number up/down step by step.
Info
View played track information
EQ
Hold button for 3 seconds to open the menu.
Audio menu
The Audio menu button gives you the possibility to adjust your sound system with the following options Bass, Treble, Balance and Fader.
These options can be used to fine tune your sound.
Mode
The mode button allows you to go from one source to another source (f.i. Tuner) by pushing the button as many times as needed.
Scan (tuner)
Each found station will be played for 5 seconds
AS
AS stands for Autostore; in tuner mode it will automatically store the 6 strongest stations (M1-M6). Note: all previous stored stations are lost
PS
PS stands for Preset stations this means that when you push this button in tuner mode it will automatically switches to the first preset (M1)
then it will go to the next and so on.
Rotary volume
This knob allows you to adjust the volume from minimum to maximum level. NOTE high sound levels may cause damage to your ears
M1-M6
These are the preset stations where you can store your favorite radio stations if in tuner mode
Pause/Play
This button allows you in CD, USB or SD mode to play or to pause the music.
INT
INT will play 10 seconds of each song on the USB or SD. If the preferred song is playing, push again and it will play that song
Repeat
Repeat will play a selected song or album continuously. Available in USB and SD mode
Random Shuffle will play all the songs random. Available in USB and SD mode
File/track down/up In MP3 mode press this button to go up or down one track. Press key nr. 16 and 17 to go up/down by 10 tracks.
Fast forward/backward Long press to fast forward to the CD, USB or SD
Seek up/down Long press to move to the next station automatically
3,5mm AUX in Jack To connect an external audio system
USB input When inserting a USB stick the unit will switch to USB mode. (Max 1000 tracks)
SD card input
When inserting a SD card the unit will switch to SD mode. (Max 4GB SDHC card, max 1000 tracks)
reset (behind panel) Use a non-metallic pointed object to press and hold the reset button for 5 seconds. The unit will be set to factory default.
RCD 266
4 10 18 22 19 12
Long press Short press
EQ
AF
TA
PTY
PS
M1
M2
M3
M4
M5
M6
Loud Band
Tune down
Tune up
Scan
Description of the functions
Note! Do not operate the unit while driving.
5 8 20 1 3 21 9 11
4x 75WATT
13 14 15 16 17 7
TUNER
Long press
Panel release button
3.5mm AUX in Jack
AS
Memory 1
Memory 2
Memory 3
Memory 4
Memory 5
Memory 6
Seek down
Seek up
RCD266
English
CD/MP3/WMA
Short press Long press
Ok
Pause/play
Repeat track
Repeat all
INT
Random
track down -10
track up +10
Info
track down Fast backward
track up Fast forward
