Caliber RCD 263 Schnellstartanleitung

SYSTEM
KEY
Short press Long press
1 Power
Rotary volume
2
Audio menu
3 Menu (system)
4 Panel release
5
6
7
8
9 Mode
10 Display
11 Equalizer
12
13
14
15
16
17
18
19
20
21
22
23
24
25
Panel release Push this button to release the frontpanel
Eject Push this button to eject the CD out of the unit
Power Power function to activate or deactivate the unit.
Band Band selection allows you to select di erent reception bands, f.i. FM1, FM2 and FM3
OK Confirm input
AF AF stands for Alternative frequencies; the tuner will return to alternative frequencies whenever the reception signal is getting worse
TA TA stands for Tra c announcement which means that it will give you information about the tra c (if broadcasted) no matter what mode you
are in (CD,USB, etc.) it will automatically interrupt the cd and give the information, after that it automatically switches back to the selected
mode
REG REG stands for Regional program operation. Long press REG will allow tra c announcement from strong stations to come through. Long
press REG again will allow all received tra c announcement to interupt CD play or radio listening
PTY The PTY function allows you to search for stations with a particular program type. You can choose between PTY MUSIC and PTY SPEECH using PTY
button. Under each group you can choose from the following programs, using the 1~6 present buttons:
PTY music: 1. POP M, ROCK M / 2. EASY M, LIGHT M / 3. CLASSICS, OTHER M / 4. JAZZ, COUNTRY / 5. NATION M, OLDIES / 6. FOLK M
PTY speech: 1. NEWS, AFFAIRS, INFO / 2. SPORT, EDU / 3. CULTURE, SCIENCE / 4. WEATHER, FINANCE, CHILDREN / 5. SOCIAL, RELIGION / 6. TRAVEL
Seek up/down Short press to move to the next station automatically
Tune up/down Long press to move the radio frequency number up/down step by step.
Menu (system) Hold button for 2 seconds to open the menu. TA SEEK or TA ALARM - PI SOUND or PI MUTE - RETUNE L or RETUNE S - MASK DPI or MASK ALL -
TAVOL 17 (tra c announcement volume) - CLOCK 24 or 12 (Clock format) - BEEP ON/OFF (beep sound on/o ) - EXIT
Audio menu The Audio menu button gives you the possibility to adjust your sound system with the following options Bass, Treble, Balance and Fader.
These options can be used to ne tune your sound
Equalizer The Equalizer button allows you to select your desired audio mode. Press repeatedly to view modes FLAT - CLASSICS - POP M - ROCK M -
DSP OFF
Mode The mode button allows you to go from one source (f.i. CD) to another source (f.i. Tuner) by pushing the button as many times as needed
AMS (AS) AS stands for Autostore; in tuner mode it will automatically store the 6 strongest stations (M1-M6). Note: all previous stored stations are lost
AMS (PS) PS stands for Preset stations this means that when you push this button in tuner mode it will automatically switches to the rst preset (M1) if
you push again it will go to the next and so on
Rotary volume This knob allows you to adjust the volume from minimum to maximum level. NOTE high sound levels may cause damage to your ears
M1-M6 These are the preset stations where you can store your favorite radio stations if in tuner mode
Pause/Play This button allows you in CD, USB or SD mode to play or to pause the music
Scan Scan will play 10 seconds of each song on the CD, USB or SD. If the preferred song is playing, push again and it will play that song
Repeat Repeat will play a selected song or album continuously. Available in CD, USB and SD mode
Shu e Shu e will play all the songs random. Available in CD, USB and SD mode
10 tracks down/up In MP3 mode press this button to go up or down
Track down/up In MP3 mode press this button to go up or down one track
Fast forward/backward Long press to fast forward to the CD, USB or SD
3,5mm AUX in Jack To connect an external audio system
USB input When inserting a USB stick the unit will switch to USB mode. (Max 1000 tracks)
SD card input Remove the frontpanel to insert SD card. When inserting a SD card the unit will switch to SD mode. (Max
Reset (behind panel) Use a non-metallic pointed object to press and hold the reset button for 5 seconds. The unit will be set to factory default
TUNER
Short press Long press
Disc slot
LCD Display
USB port
Mode
AMS (PS) AMS (AS)
Band
Seek down Tune down
Seek up Tune up
PTY
AF REG
TA
M1 Memory 1
M2 Memory 2
M3 Memory 3
M4 Memory 4
M5 Memory 5
M6 Memory 6
3,5mm AUX in Jack
Description of the functions
10 tracks
Note! Do not operate the unit while driving.
CD/MP3/WMA
Short press
OK
Eject
Mode
Enter
Track down Fast backward
Track up
Play/Pause
Scan
Repeat
Shu e
10 tracks down
10 tracks up
4 GB card, max 1000 tracks)
Long press
Fast forward
