Chasing F1 Introduction

Fish Detector

CHASING F1 is a hi-tech digital full HD fish finder drone with remote control designed for all types of fishing.
It is a must-have for every angler of every skill level who desires to maximize his/her catch rate. F1 provides
you with intelligent information about the underwater terrain, surroundings, other objects underneath, the
location of fish masses, and the position of fish in water. In addition to fishing situations, F1 delivers both
real-time water temperature readings and accurate depth readings. It has the ability to take both great
quality pictures and to capture high-definition videos during the process of fishing. With built-in waterproof
full HD digital stellar camera equipped with white LED and IR highlight night-vision lights, fishes can be
caught in sight and video-recorded more clearly in the dark environment. F1 moves vertically and can
ascend and descend automatically. The maximum operating depth of F1 is 28 meters. It is featured by four
thrusters and has various functions, such as GPS, all-directional movement, suspension and stop, keeping
records of multiple fishing points, automatic cruise between fishing locations and one-key return. The
lithium battery is swappable and can last up to 6 hours in continuous use. Apart from the above-mentioned
functionality, F1 can be also mounted with smart sonar ball, small bait boat, and other optional accessories
to undertake more tasks.
2
8
9
2
1. Power button
2. Thruster
3. Antenna mounting base
4. Hanging buckle
5. Peripheral interface
6. Reset Button
(Short press to switch 2.4Ghz or 5Ghz WiFi)
7. MicroSD slot
8. Navigation light
9. Locking screw
10. Hanging ring
11. Antenna
12. Battery
13. Camera probe connector
14. Camera probe
15. IR Infrared Light
16. Quick Release Pin
17. Lead weight
03
6
7
11
11
10
12
13
16
14
15
17

Sonar Bracket

1. Hanging buckle
Bait Boat （ optional）
1. Hanging buckle
2. Connection interface
3. Baffle
4. Switch block
5. Connection cable
2
1
3
Installation & Connection
5
3
9
Download CHASING GO2 App
2 1
CHASING GO2 App：
Scan QR code or visit iOS App store / Google Play
to download. (iOS 9.0 / Android 5.0 and above)
Install Fish Detector
2
a. Install Antennas：
4
Screw the two antenna mounts securely on
the drone and tighten them.
1
1
3
2
4
b. Install Camera Probe：
· Connect the connector of the Fish Detector to the
Camera probe cable socket (shown in ①) and
tighten the nut.
· Align the cable clamp of the Fish Detector with
the mounting hole of the Camera probe (shown
in ②), then gently push the Quick Release Pin into
the hole.
①
5
②
