Battery Charging Guidance

（1） Press the limit buckle on the bottom of the Fish
Detector to remove the battery.
（2） Connect the power cord to charge the battery.
A solid red light indicates normal charging is in
process. A solid green light indicates a complete
charge. After charging, please unplug the power
adapter.
Specifications
Fish Detector
Size(mm) 278x154x215
Weight 2KG
Max Depth 28M
Wire Length 28.5M
Working Time 4-6 Hours
Battery Cycle Times >300 Times
Working Temperature -10℃~45℃
Sensor
Triaxial Gyroscope
IMU
Accelerometer / Compass
Depth Sensor
＜±0.25m
Temperature Sensor ＜±2℃
GPS
±1m
LED
IR Infrared Light 7*IR Infrared Light LED
The transmission frequency： 20dBm
Transmission power： 2412MHz-2484MHz/5150MHz-5250MHz.

Maintenance and Safety Precautions

1 Navigation Safety
Relatively clear water
Open water
quality, no dense
navigation
aquatic plants
09
②
①
Camera
CMOS 1/2.8
Light Ring F2.0
Focal Distance 2.7mm
ISO Range 100-102400
Viewing Angle 164.6°
Photo Maximum Two-mega-pixel
Resolution （1920*1080）
Photo Form JPEG
Video Resolution 1080P@30fps
Video Maximum Bitstream 4M
Video Form MP4
Standard 16G (maximum
SD Card Memory
support 256G)
Charger
Power 2A/12.6V
Charging Time 3.5H
No dense radio or
radar signals
2
Battery Protection
Do not run out Charge when power
of battery power is less than 25%
3 Charging Protection
· Only use the Chasing standard adapter；
· Red light means charging；
· Green light means fully charged.
4 Thruster/ Propeller
Do not touch the Thrusters
after unlocking.
5 Winding
1) Please pay attention to adjust the winding speed to a slow speed to avoid damage to the probe or cable.
2） Please stop winding if the Camera probe depth remains unchanged for more than half a second.
3） Please do not winding when the Fish Detector is out of water.
Other
1. Pay attention to the orientation when installing the battery to avoid violent removal and damage to the
battery.
2. Before launching into the water, please check whether the connections are firm, whether the thrusters
are loose, and ensure the top MicroSD waterproof sealing cover is properly installed and fastened.
3. After each use, please check whether the motor blade is entangled with aquatic plants, fishing nets and
other foreign objects. Meanwhile, rinse the drone body with fresh water, dry it, air it, and then put it back
into the packing box.
4. Do not bend the antenna to avoid damage
5. When not in use, the waterproof cover shall be screwed on tight to avoid corrosion of the interface.
6. Do not place heavy objects on drone or accessories to avoid possible damage.
7. Children under the age of 16 must be accompanied by an adult to use the drone.
8. When not in use, please do not expose the Fish Detector and accessories under sunlight. Store it in a
cool place or in a special box.
Support
1. Any questions about our products please contact by support@chasing-innovation.com or leave a
message on the Chasing Website (https://www.chasing.com) chatting window.
2. You can also join the OFFICAL CHASING OWNERS GROUP on Facebook for latest news, app update and
other shared stories with Chasing Products worldwide.
You could have the latest user manual by the
https://www.chasing.com
This content is subject to change without prior notice
When not in use,
Working
keep battery power
temperature
at 50% - 80%
-10 °C ~ 45 °C
Do not unlock the Thruster for more than
30 seconds in the air to avoid overheating.
