3 Construction

Principal parts:

• Carrier Assembly with Pyramid (aluminum/St. Stl./titanium)
• Heel & Toe Springs (e-carbon)
• Spring attachment screws (titanium/St. Stl.)
• Glide Sock (UHM PE)
• Foot shell (PU)
Pyramid
Carrier Assembly
Toe Spring
Toe spring
Screw
Heel
Spring
Heel Spring Screws
Glide
Foot
Sock
Shell
