About the device
2.4 First time operation
After all necessary connections have been made,
switch the UPS on by pressing the button
The display will light up and the green LED should
indicate mains supply is present. The display shows
the load level in %, as well as the operation mode in
the little flow chart. In case the
pull the mains cord (at the mains socket) and plug it in
again, rotated by 180°.
The device is now ready to work.
8 1 9 10 11 12
3
8. Anzeige für erschöpfte Batterien
9. Bypass-Anzeige
10. Anzeige Stromnetzspannung zu schwach
11. Anzeige Stromnetzspannung zu stark
12. Anzeige USV-Ausgang vorhanden
13. Anzeige falsche Erdung
14. Überlastanzeige
15. Anzeige Prozent der Batterieladung
16. Wahltaste Anzeige der Batterieladung
22
24
1. Led für Stromnetzanschluss
23
2. Alarmleuchte (Led)
25
3. Taste ON
4. Taste OFF
Operating Guide
5. Batterie auswechseln
Informer Compact UPS Series
symbol is blinking,
6
13
5
14
2
4
16
6
2 1
17 18 19
20 21
IN
OUT
USB
RS232
3 100 08
3. Front panel elements
1 - LED/Symbol „Mains OK"
for >4s.
Mains operation is the normal operation of the UPS, if
mains voltage is present. The output voltage is provided
to the output via a transformer and is held constant.
2 - LED/Symbol „Error"
Indicates errors like overload, short-circuit at the output
or other errors. Is accompanied by an audible alarm.
3 - Button ON
This button is used to switch the UPS on by pressing it
>4s, as well as to mute the audible alarm (press >2s)
15
until a new error occurs.
4 - Button OFF
Is used to switch the UPS off (press >4s).
5 - Symbol „Battery replacement"
Indicates an insufficient capacity and a probably bad
condition of the batteries. Once this is indicated, they
should be maintained, i.e. replaced.
6 - LED/Symbol „Battery operation"
Indicates that the battery operation is active, because of
mains loss or because the mains voltage has dropped
by more than 25%.
In case the LED is flashing, while the UPS is switched
off, this indicates that the batteries are charged.
7 - Screw for battery cover
8 - Symbol „Low battery"
Indicates a low battery level and warns against immi-
nent shutdown of the UPS.
7
9 - Flow chart
Shows symbolically the current flow inside the UPS
and thereby the operation modes.
10 - Symbol „Mains low"
Indicates that the mains voltage has dropped down by
-9% or more. The UPS compensates this with +15%
voltage increase (boost).
11 - Symbol „Mains high"
24
Indicates, that the mains voltage is too high (9% or
more). The UPS will then compensate this by -15%
(buck).
25
12- Symbol LOAD
Indicates voltage is present at the output.
/ SILENCE
8 1 9 10 11 12
3
8. Anzeige für erschöp
9. Bypass-Anzeige
10. Anzeige Stromnetzs
11. Anzeige Stromnetzs
12. Anzeige USV-Ausga
13. Anzeige falsche Erdu
14. Überlastanzeige
Date: 04-06-2018
EN
6
13
4
16
11
