9. Specifications
•
Operating voltage range
Power consumption
•
•
Temperature range
•
Humidity
•
DTE baud rate (M-Bus mode)
•
Single-bit distortion (M-Bus mode)
•
Data communications speeds
(standard mode)
•
Data communications standard
(standard mode)
•
Fax transmission standard
(standard mode)
•
DTE data format (standard mode)
•
Housing
•
Dimensions of housing
•
Displays
•
Connectors
•
Approval
M-Bus - MODEM
GmbH, Stettiner Str. 38, D-33106 Paderborn
9–35V DC
typ. 1 W, max 3 W (online)
0 to 60°C,
-10°C to 60°C storage
5–95% (non-condensing)
300 or 2400 baud
max. ±1/6 bit time at 2400 baud and, or ±1/48
bit time at 300 baud (not cumulative)
300 to14400 baud (fax 2400 to14400 baud)
or up to 33600 baud for newer revisions
V.21/V.22/V.22bis/V.23/V.32/V.32bis/V.34
V.34+/MNP5/V.42/V.42bis
V.17/V.27ter/V.29/EIA Class II, Group 3
300 to 115200 baud; 7 or 8 data bits; 1 or
2 stop bits; even, odd or fixed parity
Light-grey plastic jousing, with DIN rail clip
94 x 35 x 77 mm (l x w x h) without sockets
and DIN rail clip
2 LEDs for power and line status
- plugable screw terminal for power supply
(wire ∅ max. 1,5mm
- D-SUB 9-pin socket für RS232C
- Phone cable socket RJ45
CE conformity
2
)
13.12.11, Version 3.0
Seite / Page 15
