MALFUNCTION POSSIBLE CAUSE
1. The pump is not 1. No current.
discharging
any liquid, the motor 2. Thermal motor protection feature has
is not triggered.
running.
3. The capacitor is defective.
4.
Blocked running wheel
2. The motor is running, 1. The pump housing is not filled with liquid.
but the
pump is not 2. Air penetrates into the intake line.
discharging any
liquid.
3. Suction height and/or discharge height too
great.
4.
Clogged suction line.
5.
Pressure line clogged.
3. The pump stops after 1. The electrical supply does not correspond to
a short the information given on the type plate.
time of operation
because the 2. Pump or intake line are blocked by solids.
thermal motor 3. Liquid is too viscous.
protection
feature has triggered. 4. Temperature of liquid or environment is too
high.
5. Pump is running dry.
4. Intermittent or erratic 1. Running wheel obstructed by solids.
operation. 2. Please refer to item 2.
3. Please refer to item 3.4.
4. The mains voltage out of the tolerance range.
5. Motor or running wheel defective.
5. The volume of the 1. Please refer to item 2.1.-2.5.
liquid being 2. Worn running wheel.
discharged is too
small.

8. Warranty

The present device was manufactured and inspected according to the latest methods. The seller warrants for
faultless material and workmanship in accordance with the legal regulations of the country in which the device
was purchased. The warranty period begins with the day of the purchase and is subject to the provisions below:
Within the period of warranty, all defects which are to be attributable to defective materials or manufacturing will
be eliminated free of charge. Any complaints are to be reported immediately upon their detection.
The warranty claim becomes void in the case of interventions undertaken by the purchaser or by third parties.
Damage resulting from improper handling or operation, incorrect setting-up or storage, inappropriate connection
or installation or Acts of God or other external influences are excluded from warranty.
Parts being subject to wear and tear, such as the pump wheel (impeller) and mechanical shaft seals are excluded
from warranty.
14
ELIMINATION
1. Please verify the presence of voltage and the
correct position of the plug.
2. Separate the pump from the electrical
mains, allow the system to cool down, eliminate
cause.
3. Please contact the customer service
department.
4. Eliminate reason of blockage.
1. Fill the pump housing with liquid (please refer to
"Putting into operation" section).
2. Check to make sure that:
a) The connection points of the intake line are
b) tight;
The inlet opening of the intake line including the
check valve are immersed into the liquids being
c) discharged;
The check valve with the filter is tight and not
d) jammed;
No siphons (i.e. permanently liquid-filled loops),
kinks, counter-slopes or narrow spots are
3. present along the intake lines.
Change the arrangement of the installation so
that the suction height and/or discharge height
4. will not exceed the max. value.
5. Remove cause of clogging.
Remove cause of clogging.
1. Check the voltage of the supply cable.
2. Remove possible congestion.
3. Pump may not be suitable for this liquid. If
feasible, the liquid should be thinned.
4. Make sure that the temperature of the liquid
being pumped and the environment do not
exceed the max. admissible values.
5. Eliminate causes of dry-running.
1. Remove solids.
2. Please refer to item 2.2.
3. Please refer to item 3.4.
4. Please make sure that the mains voltage
matches the data on the type plate.
5. Please contact the customer service
department.
1. Please refer to item 2.1.-2.5.
2. Please contact the customer service
department.
