10. MAINTENANCE AND REPLACEMENT OF BULB (cod.11B20-11FM20-11BX5-11FMX5)
(TO BE PERFORMED BY QUALIFIED STAFF OR SPECIALIZED TECHNICIAN)
• THE GUARANTEE DOES NOT COVER REPLACEMENT OR REPAIR OF BULB.
• REPLACEMENT OF BULB IS TO BE PERFORMED ONLY BY PROFESSIONALLY QUALIFIED PERSONNEL OR BY A SERVICING CENTRE.
• REMOVE DUST FROM THE REFLECTOR AND BULB PERIODICALLY WITH BRUSH OR COMPRESSED AIR FOR CONSTANT HELIOSA® HI
DESIGN 11 HEAT EFFICIENCY.
• THE REPLACEMENT BULB MUST BE THE SAME AS THE BULB SUPPLIED WITH THE DEVICE.
• REPLACEMENT WITH OTHER BULBS MAY DAMAGE THE DEVICE AND CAUSE IT TO BE UNSAFE. CONTACT STAR PROGETTI OR THE
RETAIL OUTLET AUTHORIZED TO SELL THE REPLACEMENT BULB, SPECIFYING THE MODEL AND CODE OF THE PURCHASED HEATER.
• THE INJECTION POINT ON THE BULB (c) MUST ALWAYS FACE OUTWARDS.
BEFORE PROCEEDING WITH THE BULB REPLACEMENT, OPERATORS MUST:
- FULLY DISCONNECT THE DEVICE FROM POWER SUPPLY AND MAKE SURE THE BULB IS COLD
- NOT TOUCH THE BULB WITH THEIR BARE HANDS
REPLACEMENT OF BULB (COD. 11B20-11FM20)
1. HELIOSA HI DESIGN 11
3. UNSCREW THE SCREWS OF THE CLAMPS TO WHICH
THE TWO BULB CORDS ARE CONNECTED.
2. UNSCREW THE 4 SCREWS ON THE BACK AND
REMOVE THE 2 SIDE COVERS AND THE 2 FRONT
COMPONENTS OF THE REFLECTOR
4. REMOVE THE BULB FROM THE SPRING CLIPS. INSERT
THE NEW BULB INTO THE SPRING CLIPS, THE
SHORTENED CORDS OF WHICH ARE TO BE INSERTED
INTO THE CLAMPS. REASSEMBLE THE DEVICE BY
PERFORMING THE ABOVE TASKS IN REVERSE ORDER.
