Step 4. [Use Screw E (#16) & Screwdriver (#24)
for this step] Attach Right Drawer Slide Support
(#11) to the Back Frame (#4), making sure the
"Top" of Right Drawer Slide Support (#11) is
closest to the Solid Hardwood Board (#8). Again,
the Top is i di ated y a sti ker o o e of the
vertical columns. Note: the Drawer Slides will
face those on the Left Side Panel (#1).
Step 5. [Use Screw E (#16) for this step] Attach
Left Side Panel (#1) to Back Frame (#4). Again,
the "Top" of the Side Panel should be on the
Stainless Steel Top (#8).
Step 6. [Use Screw E (#16) and Screw B(#18) &
Washer (#17) for this step] Using Screw B (#18)
and Washer (#17), attach the "Top" of the Front
Frame (#3) to the Stainless Steel Top (#8). Then,
using Screw E (#16), attach the Right Drawer Slide
Support (#11) and both Right & Left Side Panels
(#1 & #2) to the Front Frame (#3).
