Operating instructions -- PowerMax cam unit PMU
PowerMax cam unit SN5650-PMU-0065 — SN5650-PMU-0260
9.1 Mounting of the mounting plate at cam widths 0065-02030
(only Premium)
Step 1
Before pushing the mounting plate back in the groove guidance it is absolutely necessary to clean the stop
lug (AN) and the t-nut guidance of both components.
Step 2
Fix the mounting plate with the securing screw again.
picture 1
picture 2
AN
14
