Transport and Storage

 Transport and store the device carefully and in accordance with the safety notes
(see Chapter "Safety").
5

Mounting and Installation

5.1

Assembly

 Mount the device carefully and only in accordance with the safety notes
(see Chapter "Safety").
 Read through the following installation conditions and assembly instructions carefully and
follow them precisely.

5.1.1 Operating Position

DANGER! Explosion resulting from damage to the seal!
Non-compliance may result in serious or even fatal injuries.
 Do not damage the seal when mounting.
The operating position is optional.
Exception: To prevent water from getting in when the flap is opened, the hinge must not be
attached at the bottom.
156037 / 8611601300
2020-09-21·BA00·III·en·06
