10. ENERGY EFFICIENCY.................. 17 WE’RE THINKING OF YOU Thank you for purchasing an Electrolux appliance. You’ve chosen a product that brings with it decades of professional experience and innovation. Ingenious and stylish, it has been designed with you in mind. So whenever you use it, you can be safe in the knowledge that you’ll get great results every time.
ENGLISH instructions in a safe and accessible location for future reference. 1.1 Children and vulnerable people safety This appliance can be used by children aged from 8 • years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning the use of the appliance in a safe way and understand the hazards involved.
Seite 4
CAUTION: The cooking process has to be supervised. • A short term cooking process has to be supervised continuously. WARNING: Danger of fire: Do not store items on the • cooking surfaces. Metallic objects such as knives, forks, spoons and lids •...
ENGLISH 2. SAFETY INSTRUCTIONS with the power supply. If not, contact This appliance is suitable for the an electrician. following markets: IT • Make sure the appliance is installed correctly. Loose and incorrect 2.1 Installation electricity mains cable or plug (if applicable) can make the terminal WARNING! become too hot.
2.3 Gas connection heated objects away from fats and oils when you cook with them. • All gas connections should be made • The vapours that very hot oil releases by a qualified person. can cause spontaneous combustion. • Before installation, make sure that the •...
ENGLISH • Do not let acid liquids, for example • Do not clean the burners in the vinegar, lemon juice or limescale dishwasher. remover, touch the hob. This can 2.6 Disposal cause matt patches. • Discoloration of the enamel has no WARNING! effect on the performance of the Risk of injury or suffocation.
Make sure that the gas type of gas you use (see table in supply pressure of the "Technical Information" chapter). appliance obeys the 4. Assemble the parts, follow the same recommended values. procedure backwards.
ENGLISH 3.7 Assembly agree with the voltage and the power of the local power supply. • This appliance is supplied with a mains cable. It has to be supplied with a correct plug which can hold the load that the rating plate rates. Make sure that you install the plug in a correct socket.
If a furniture unit is installed at a distance of 400 mm above the hob, there must be a minimum safety distance of 50 mm to the left or right from the edge of the hob. A) supplied seal...
ENGLISH Kitchen unit with door A. Removable panel B. Space for connections Kitchen unit with oven The electrical connection of the hob and the oven must be installed separately for safety reasons and to let easy remove oven from the unit. min 6 mm min 30 mm min 20 mm...
5. DAILY USE WARNING! If after some tries the burner Refer to Safety chapters. does not light, check if the crown and its cap are in correct positions. 5.1 Burner overview WARNING! Do not keep the control knob pushed for more than 15 seconds.
ENGLISH WARNING! Always turn the flame down or switch it off before you remove the pans from the burner. 6. HINTS AND TIPS 6.2 Diameters of cookware WARNING! Refer to Safety chapters. Use cookware with diameters applicable to the 6.1 Cookware size of burners.
7. CARE AND CLEANING when you wash the pan supports by WARNING! hand and dry them. If necessary, Refer to Safety chapters. remove stubborn stains with a paste cleaner. 7.1 General information 3. After you clean the pan supports, make sure that they are in correct •...
Seite 15
ENGLISH 8.1 What to do if... Problem Possible cause Remedy There is no spark when The hob is not connected Check if the hob is correct‐ you try to activate the to an electrical supply or it ly connected to the electri‐ spark generator.
8.3 Labels supplied with the accessories bag Stick the adhesive labels as indicated below: MOD. MOD. MOD. TYPE PROD.NO. IP20 PROD.NO. PROD.NO. SER.NO. 0049 SER.NO SER.NO 03 IT DATA DATA MADE IN ITALY A. Stick it on Guarantee Card and send C.
NOMINAL GAS FLOW g/h POWER POWER MARK G30 28-30 G31 37 mbar mbar Rapid 0,75 Semi-rapid 0,45 Auxiliary 0,33 10. ENERGY EFFICIENCY 10.1 Product information according to EU 66/2014 Model identification RGG7252OOX Type of hob Built-in hob Number of gas burners...
Centre middle - Rapid 56.9% Left rear - Semi-rapid 59.6% Energy efficiency per gas burner Right rear - Rapid 55.3% (EE gas burner) Left front - Semi-rapid 59.6% Right front - Auxiliary not applicable Energy efficiency for the gas hob 57.9%...
9. TECHNISCHE DATEN..................34 10. ENERGIEEFFIZIENZ..................36 WIR DENKEN AN SIE Vielen Dank, dass Sie sich für ein Gerät von Electrolux entschieden haben. Sie haben ein Produkt gewählt, hinter dem jahrzehntelange professionelle Erfahrung und Innovation stehen. Bei der Entwicklung dieses großartigen und eleganten Geräts haben wir an Sie gedacht.
Verwendung des Geräts übernimmt der Hersteller keine Haftung. Bewahren Sie die Anleitung immer an einem sicheren und zugänglichen Ort zum späteren Nachschlagen auf. 1.1 Sicherheit von Kindern und schutzbedürftigen Personen Das Gerät kann von Kindern ab 8 Jahren und •...
Seite 21
DEUTSCH Schalten Sie das Gerät nicht über eine externe • Zeitschaltuhr oder eine separate Fernsteuerung ein. WARNUNG: Kochen mit Fett oder Öl auf einem • unbeaufsichtigten Kochfeld ist gefährlich und kann zu einem Brand führen. Versuchen Sie NICHT einen Brand mit Wasser zu •...
Überspannungskategorie III gewährleistet sein. Dies gilt nicht für das Erdungskabel. Wenn Sie das Netzkabel verlegen, achten Sie darauf, • dass es keinen direkten Kontakt mit Teilen hat, die Temperaturen erreichen können, die mehr als 50 °C über der Raumtemperatur liegen. (Verwenden Sie ansonsten Isolierschläuche.)
DEUTSCH Wenden Sie sich anderenfalls an eine werden können), Erdschlüsse, Elektrofachkraft. Kontakte. • Achten Sie darauf, dass das Gerät • Die elektrische Installation muss eine ordnungsgemäß montiert wird. Wenn Trenneinrichtung aufweisen, mit der freiliegende oder ungeeignete Sie das Gerät allpolig von der Netzkabel oder Netzstecker (fall Stromversorgung trennen können.
Seite 24
• Bedienen Sie das Gerät nicht mit • Vergewissern Sie sich, dass die feuchten oder nassen Händen oder Flamme nicht erlischt, wenn Sie den wenn es mit Wasser in Kontakt Einstellknopf schnell von der gekommen ist. höchsten zur niedrigsten Stufe •...
DEUTSCH • Reinigen Sie die Brenner nicht im • Schneiden Sie das Netzkabel in der Geschirrspüler. Nähe des Geräts ab, und entsorgen Sie es. 2.6 Entsorgung • Drücken Sie die äußeren Gasrohre flach. WARNUNG! 2.7 Service Verletzungs- und Erstickungsgefahr. • Wenden Sie sich zur Reparatur des Geräts an einen autorisierten •...
3.4 Einstellen der niedrigsten Stufe So stellen Sie die niedrigste Stufe der Brenner ein: 1. Zünden Sie den Brenner. 2. Drehen Sie den Knopf auf die kleinste Flamme. 3. Ziehen Sie den Einstellknopf ab. 4. Stellen Sie mit einem kleinen A.
Seite 27
DEUTSCH 3.7 Montage • Schließen Sie das Gerät nur an eine ordnungsgemäß installierte Schutzkontaktsteckdose an. • Stellen Sie sicher, dass der Netzstecker nach der Montage noch zugänglich ist. • Ziehen Sie nicht am Netzkabel, wenn Sie das Gerät von der Stromversorgung trennen möchten.
Befindet sich 400 mm über dem Kochfeld ein Einbaumöbel, muss ein Sicherheitsabstand von mindestens 50 mm links oder rechts von der Kochfeldkante eingehalten werden. A) Mitgelieferte Dichtung B) Mitgelieferte Klammern VORSICHT! Montieren Sie das Gerät nur in einer flachen Arbeitsplatte.
DEUTSCH 3.9 Einbaumöglichkeiten min 30 mm Die unter dem Kochfeld eingebaute Platte muss sich leicht entfernen lassen und einen einfachen Zugang min 20 mm ermöglichen, falls eine Reparatur (max 150 mm) erforderlich wird. 60 mm Küchenschrank mit Tür A. Entfernbare Platte B.
5.1 Brennerübersicht Falls sich der Brenner nach einigen Versuchen nicht zünden lässt, überprüfen Sie, ob die Brennerkrone und der zugehörige Brennerdeckel korrekt sitzen. WARNUNG! Halten Sie den Knopf nicht länger als 15 Sekunden gedrückt. Sollte der Brenner nach 15 Sekunden nicht zünden, lassen Sie den...
DEUTSCH Das Kochfeld wird mit WARNUNG! Ventilen mit einem stetigen Bevor Sie das Kochgeschirr Stellverhalten geliefert. Sie vom Brenner nehmen, ermöglichen eine präzisere drehen Sie die Flamme Einstellung der Flamme. herunter oder drehen Sie sie ganz ab. 5.3 Abschalten des Brenners Drehen Sie zum Abschalten des Brenners den Knopf in die Aus-Position 6.
6.3 Deckel (separater Bausatz • Der Deckel schützt das Kochfeld vor Staub, wenn er geschlossen ist, und für vorbereitete Kochfelder) fängt Fettspritzer auf, wenn er geöffnet ist. Benutzen Sie ihn für keinen anderen Zweck. • Halten Sie den Deckel stets sauber.
DEUTSCH 7.4 Reinigen der Zündkerze beschädigen. Achten Sie darauf, dass sich niemand Verbrennungen zuzieht. Diese Funktion erfolgt über eine • Folgendes kann nach Keramikzündkerze mit Metallelektrode. ausreichender Abkühlung des Halten Sie zur Vermeidung von Kochfelds entfernt werden: Kalk- Zündschwierigkeiten diese Bauteile und Wasserränder, Fettspritzer und immer sauber;...
8.2 Wenn Sie das Problem Reparatur durch einen Techniker oder Händler eine Gebühr an. Die nicht lösen können... Informationen zum Kundendienst und die Garantiebedingungen finden Sie im Wenn Sie das Problem nicht selbst lösen Garantieheft. können, wenden Sie sich an Ihren Händler oder einen autorisierten...
9. DATI TECNICI....................52 10. EFFICIENZA ENERGETICA................53 PENSATI PER VOI Grazie per aver acquistato un'apparecchiatura Electrolux. Avete scelto un prodotto che ha alle spalle decenni di esperienza professionale e innovazione. Ingegnoso ed elegante, è stato progettato pensando a voi. Quindi, in qualsiasi momento desiderate utilizzarlo, potete esser certi di ottenere sempre i migliori risultati.
Conservare sempre le istruzioni in un luogo sicuro e accessibile per poterle consultare in futuro. 1.1 Sicurezza dei bambini e delle persone vulnerabili Questa apparecchiatura può essere usata da bambini • a partire dagli 8 anni e da adulti con limitate capacità...
Seite 39
ITALIANO Non utilizzare un timer esterno o un sistema di • controllo remoto distinto per mettere in funzione l'apparecchiatura. AVVERTENZA: Non lasciare mai il piano di cottura • incustodito durante la preparazione di cibi in quanto olio e grassi potrebbero provocare un incendio. Non tentare MAI di spegnere un incendio con •...
Quando si collega il cavo di alimentazione, assicurarsi • che non sia a contatto diretto (ad es. mediante l'impiego di manicotti di isolamento) con parti che possono raggiungere temperature superiori ai 50°C. AVVERTENZA: Servirsi unicamente di protezioni per il •...
ITALIANO 2.3 Collegamento gas può provocare il surriscaldamento del terminale. • Tutti i collegamenti del gas devono • Utilizzare il cavo di alimentazione essere eseguiti da una persona appropriato. qualificata. • Evitare che i collegamenti elettrici si • Prima di procedere con l’installazione, aggroviglino.
AVVERTENZA! l'apparecchiatura. Pericolo di incendio ed • Se si prevede un impiego prolungato esplosioni. e intenso dell’apparecchiatura, può essere necessaria un’ulteriore fonte di • Grassi e olio caldi possono rilasciare aerazione, per esempio l’apertura di vapori infiammabili.
ITALIANO • Tagliare il cavo elettrico • Utilizzare esclusivamente ricambi dell'apparecchiatura e smaltirlo. originali. • Appiattire i tubi del gas esterni. 2.7 Assistenza Tecnica • Per riparare l'apparecchiatura contattare il Centro di Assistenza Autorizzato. 3. INSTALLAZIONE AVVERTENZA! Accertarsi che la pressione Fare riferimento ai capitoli del gas di alimentazione sulla sicurezza.
Seite 44
• gas naturale G20 a 20 mbar a gas AVVERTENZA! liquido, serrare a fondo la vite di Al termine dell'installazione, by-pass. verificare la tenuta di • gas liquido a gas naturale G20 a ciascun raccordo dei tubi. 20 mbar, svitare la vite by-pass di Usare una soluzione circa 1/4 di giro.
ITALIANO min. min. 650 mm 450 mm min. 55 mm 30 mm 480 mm 560 mm A. Condotto rigido in rame o tubo flessibile in acciaio inox 3.6 Cavo di collegamento Per sostituire il cavo di collegamento utilizzare esclusivamente il cavo speciale 400 mm o un suo equivalente.
Seite 46
ATTENZIONE! Installare l'apparecchiatura esclusivamente su un piano di lavoro dalla superficie piatta. 3.8 Installazione del piano di cottura sotto la cappa da cucina Se si installa il piano di cottura sotto a una cappa da cucina, fare riferimento alle...
ITALIANO separatamente per questioni di sicurezza oltre che per consentire una facile rimozione del forno dall'unità. 4. DESCRIZIONE DEL PRODOTTO 4.1 Disposizione della superficie di cottura Bruciatore semirapido Bruciatore rapido Bruciatore ausiliario Manopole di regolazione 4.2 Manopola di regolazione Simbolo Descrizione Simbolo Descrizione...
A. Spartifiamma bruciatore ATTENZIONE! B. Corona bruciatore In assenza di elettricità è C. Candela di accensione possibile accendere il D. Termocoppia bruciatore senza utilizzare il dispositivo elettrico; in tal 5.2 Accensione del bruciatore caso sarà sufficiente avvicinarsi al bruciatore con...
ITALIANO 6.1 Pentole Bruciatore Diametro del‐ ATTENZIONE! le pentole Non usare pentole in ghisa, (mm) teglie in terracotta, grill o Rapido (centrale) 180 - 260 piastre tostapane. L’acciaio inox può brunire se Rapido (posteriore de‐ 160 - 260 sottoposto ad eccessivo stro) riscaldamento.
• I graffi o le macchie scure sulla 3. Dopo aver pulito i supporti pentole, superficie non compromettono il assicurarsi che siano riposizionati funzionamento del piano di cottura. correttamente. • Usare un prodotto di pulizia speciale 4. Per fare in modo che il bruciatore...
Seite 51
ITALIANO 8.1 Cosa fare se... Problema Causa possibile Soluzione Il gas non si accende Il piano di cottura non è Accertarsi che il piano di quando si preme il pulsan‐ collegato a una fonte di ali‐ cottura sia collegato corret‐ te di accensione.
8.3 Etichette fornite con il sacchetto degli accessori Attaccare le etichette adesive come indicato di seguito: MOD. MOD. MOD. TYPE PROD.NO. IP20 PROD.NO. PROD.NO. SER.NO. 0049 SER.NO SER.NO 03 IT DATA DATA MADE IN ITALY A. Attaccarla sul Foglietto di garanzia C.
MINIMA INIETTORE G30 28-30 G31 37 mbar mbar Rapido 0,75 Semi rapido 2,0 0,45 Ausiliario 0,33 10. EFFICIENZA ENERGETICA 10.1 Informazioni prodotto conformi alla norma UE 66/2014 Identificativo modello RGG7252OOX Tipo di piano di cottura Piano di cottura da incasso...
Numero di bruciatori a gas Centrale in mezzo - Rapido 56.9% Posteriore sinistro - Semirapi‐ 59.6% Efficienza energetica per brucia‐ tore a gas Posteriore destro - Rapido 55.3% (EE gas burner) Anteriore sinistro - Semirapido 59.6% Anteriore destro - Ausiliario...
