C60_1-023_819395_0508_en.p65
23
Description of
Input buffer
(continued)
Please note the
basic procedure on
13 and 28...35
and the examples on
pages
36...55.
24
Description of
Input buffer
(continued)
Please note the
basic procedure on
13 and 28...35
and the examples on
pages
36...55.
24
E
Function Description
Input Buffer, Configuration and Explanation
Sub-
Meaning
Function Description
address
01
Error code (continued)
Hex
09
Cable break to selected read/write head, or head not connected.
Hex
0C
The EEPROM cannot be read/programmed.
Hex
0D
Faulty communication with the data carrier.
Hex
0E
The CRC of the read data does not coincide with the CRC of
Hex
the data carrier.
0F
Contents of the 1st and 2nd bit header (1st and last bytes) of
Hex
the output buffer are not identical (2nd bit header must be
served).
11
Invoking a function that is not possible, since the processor is in
Hex
"compatible with BIS C-6_1" mode.
12
Copying not possible, since a command is already started on
Hex
Head 2.
or
Configuration 1st byte
00
Default value (factory setting).
Hex
Changes depending on the configuration.
or
Data
Data which was read from the data carrier.
(continued on next )
Function Description
Input Buffer, Configuration and Explanation
Sub-
Meaning
Function Description
address
02
Configuration 2nd byte
Hex
80
Default value (factory setting).
Hex
Does not change!
or
Data
Data which was read from the data carrier.
03
Configuration 3rd byte
Hex
00
Default value (factory setting).
Hex
Changes depending on the configuration.
or
Data
Data which was read from the data carrier.
04
Configuration 4th byte
Hex
82
Default value (factory setting).
Hex
Changes depending on the configuration.
or
Data
Data which was read from the data carrier.
05
Configuration 5th byte
Hex
00
Default value (factory setting).
Hex
Changes depending on the configuration.
or
Data
Data which was read from the data carrier.
06
Configuration 6th byte
Hex
00
Default value (factory setting).
Hex
Does not change!
or
Data
Data which was read from the data carrier.
07
2nd Bit header The data are valid if the 1st and 2nd bit headers are in
Hex
agreement.
or
Data
Data which was read from the data carrier.
E
23
