C60_1-023_819395_0508_en.p65
19
Description of
Output buffer
(continued)
Please note the
basic procedure on
13 and 28...35
and the examples on
pages
36...55.
20
Description of
Output buffer
(continued)
Please note the
basic procedure on
13 and 28...35
and the examples on
pages
36...55.
20
E
Function Description
Output Buffer, Configuration and Explanation
Sub-
Meaning
Function Description
address
03
Start address
Address for reading from or writing to the data carrier. (The High
Hex
(High Byte)
Byte is additionally used for the address range from 256 to 8,191)
or
Start address
Address for the Auto-Read function, starting at which the data
(High Byte)
carrier is to be read. The value is stored in the EEPROM. (The
High Byte is also required for the address range from 256 to
8,191).
or
Configuration 3rd byte
00
Default value (factory setting)
Hex
This value must not be changed!
or
Data
for writing to the data carrier
04
No. of bytes
Number of bytes to read or write beginning with the start address
Hex
(Low Byte)
(the Low Byte includes from 1 to 255 bytes).
or
Configuration 4th byte
82
Default value (factory setting)
Hex
Changes depending on the configuration.
or
Data
for writing to the data carrier
(continued next )
Function Description
Output Buffer, Configuration and Explanation
Sub-
Meaning
Function Description
address
05
No. of bytes
Number of bytes to read or write beginning with the start address
Hex
(High Byte)
(the High Byte is additionally used for the range between 256 and
8,191 bytes).
or
Configuration 5th byte
00
Default value (factory setting)
Hex
Changes depending on the configuration.
or
Data
for writing to the data carrier.
06
Configuration 6th byte
Hex
00
Default value (factory setting)
Hex
This value must not be changed!
or
Data
for writing to the data carrier.
07
2nd Bit header
The data are valid if the 1st and 2nd bit header are identical.
Hex
or
Data
for writing to the data carrier.
E
19
