Input/output array
Discrete outputs
Tab. 7:
Bits Outputs
O 00 Close Weld Contactor
O 01 Magnet Valve
O 02 Transformer 1
O 03 Transformer 2
O 04 Transformer 3
O 05 Transformer 4
O 06 Transformer 5
O 07 Transformer 6
O 08 Not used
O 09 Not used
O 10 Not used
O 11 Not used
O 12 Not used
O 13 Not used
O 14 Not used
O 15 Not used
6.3

Other inputs/outputs

Other inputs
Tab. 8:
Inputs
KSR
Digital pressure feedback
Other outputs
Tab. 9:
Outputs
Analog pressure output
