Connecting Your Equipment

Reference

DiSEqC 1.0 Connection
Please refer to page 15.
All our receivers are designed to be DiSEqC 1.0 and DiSEqC 1.2 compatible.
This allows multiple antennas to be connected to the STB at the same time.
If you have two or more fixed antennas or LNBs then we recommend you use a DiSEqC
1.0 switch.
Connect the coaxial cable from the first LNB to the LNB 1 or LNB A input connector of the
DiSEqC switch.
Do the same for any other LNBs that you have.
Connect one end of a coaxial cable to the RF output connector of the DiSEqC switch,
connect the other end to the LNB IN socket on the STB.
DiSEqC 1.2 Connection
Please refer to page 16.
To the digital receiver, you can connect either a single satellite antenna directly or
LNB of multi-feed equipment.
Software Upgrade procedure via personal computer
(http://www.digitallworld.com) to get more information and the new software.
1. Go to the Homepage and check the latest software to upgrade.
2. Download the latest software of your STB model to your PC directory.
3. Check the serial cable and COM1 port can work well. Connect a cable between the
COM1 port of your PC and RS-232 port of the STB.
Downloaded from www.Manualslib.com
To maintain the STB
up-to-date, it will be
possible to upgrade the
software of the STB via
personal computer.
You can find the new
version of the software
may include new or
improved functions for
the latest one. If you
want to download and
upgrade the software
via personal computer,
visit our homepage
- 12 -
Digital Satellite Receiver
manuals search engine
Connecting Your Equipment
4. Then, run the downloaded execution file by double click it on your PC or by pressing the
Stand-by button of RCU.
5. Then you can see the "S/W upgrade' box, click the
to upgrade.
6. Then, plugged out and in.
7. Then, upgrading starts, the progressive bar in the download window works, the PC will
shows the progress in window.
8. When upgrade is completed, the following message will be popped up on the window;
"S/W successfully upgraded. This program will be closed." After you check this message,
the download program will be automatically closed.
9. Then, you have to power off and on for running new software.
10. You can check correct upgrading by comparing software version in system information of
Installation menu.
11. If any error occur during each steps, go to the step 4.
- 13 -
