Connecting Your Equipment

Front Panel

1 2 3
1
STAND-BY
2
CHANNEL-
3 CHANNEL+
4 CAM Slots
(Depending on model)
Downloaded from www.Manualslib.com
4
(Depending on model)
To Switch between Operation and Standby mode.
To change channels down.
To move down highlight marked cursor.
To change channels up.
To move up highlight marked cursor.
2 Slots for Common Interface CAM with SmartCard
- 8 -
Digital Satellite Receiver
manuals search engine
Connecting Your Equipment

Rear Panel

1 2 3 4 5
1 VIDEO
2 AUDIO
3 TV OUT
4 ANT IN
5 VCR
4
6 TV
6 7 8 9 10 11 12
To connect video to a 7 OPTICAL
TV using RCA jack.
To connect audio R/L to 8 RS-232
a TV or an Audio Amp
or System.
9 LOOP THROUGH
To connect to a TV via a
coaxial cable.
10 LNB
To connect to TV ANT
input.
11 ANT IN
To connect this port to
that of a VCR via scart
cable. 12 LOOP THROUGH
To connect this port to
that of a TV via scart
cable.
- 9 -
To connect S/PDIF
cable.
To connect to a PC for
S/W upgrade.
To connect to the other
satellite receiver.
To connect to a satellite
antenna.
To connect the terrestrial
antenna here.
Used to connect a RF
signal from the STB to
either the RF input
jack (antenna) on your
VCR or to the antenna
input of your TV
Digital Satellite Receiver
