Bertilo Pento BCPE3 Aufbauanleitung Seite 3

BCPE3(NF/GR/AN)
ID Details in mm (Tolerance/Toleranz ...-+ 2mm)
19 x 45 x 989
40 x 60 x 1878
15 x 15 x 837
Ø4,5 x 90
Ø4,5 x 75
Ø4,5 x 50
Ø4 x 25
Ø1,5 x 25
ES60 (30/30)
60 x 554 x 1953
Pcs. ID Details in mm (Tolerance/Toleranz ...-+ 2mm)
40 x 60 x 1878
x 1
40 x 60 x 989
x 1
15 x 15 x 324
x 6
3 x 1000 x 3700
x 16
NB! Roofing felt for initial covering!
40 (41) x 60 (41)x 500
x200
Ø3,5 x 35
x149
Ø3 x 19
x 20
Ø3 x 14
x 36
VR1515
Ventilation rest
x 1
15 x 15 x 909
x 2
12 x 200 x 200
X 2
Pcs.
x 1
x 1
x 6
x 3
x 8
x122
x 8
x
216
x 2
x 1
x 2
3
