4.4 PoE Function
The IMC-1F1T provides a way to supply power conveniently and easily for any
IEEE 802.3at/802.3af devices that need to be powered on. The IMC-1F1T needs
DC 12-48V or AC 24V input and it injects the DC power into the pin of the twisted
pair cable (Pins 1, 2, 3 and 6).
0m-120km
Fiber Switch
- 12 - EN
DC 12V-48V,AC 24V Output
Data
Power Line (AC)
AC
Power Line (DC)
DC
Industrial DIN Rail
Power Supply
DC
IMC-1F1T
100 meters
AC
Data Power
1000BASE-X Fiber Cable
1000BASE-T Ethernet Cable with PoE
PoE+
Speed Dome
