4.3 Cable Connection

Installing the SFP Transceiver
The sections describe how to insert an SFP transceiver into the SFP slot on
IMC-1F1T. The SFP transceiver can be plugged into the SFP port without having
to power down the IMC-1F1T.
Before connecting to other switches, workstation or Media Converters, please
make sure both sides of the SFP transceivers are the same type, for example,
1000Base-SX to 1000Base-SX, 1000Base-LX to 1000Base-LX.
Connecting the Fiber Cable
1. Connect one end of a ber optic cable to the SFP transceivers.
2. Connect the other end of the cable to a Switch, ber NIC or a Media Converter.
Connecting the Ethernet Network Cable
1. Connect an Ethernet cable to the 10/100/1000Base-T RJ45 port on the
IMC-1F1T.
2. Connect the other end of the Ethernet cable to a Switch, ber NIC or a Media
Converter.
Be sure the connected network devices support MDI/MDI-X. If it does not
support, then use the crossover Cat 5/5e/6 cable.
Note
