INSTALLATION MANUAL
KCIEN - KCIENSBP
Illuminated Weatherproof Keypad - Self Contained
1] PRODUCT PRESENTATION
Backlit.
Stainless steel.
Compact.
Compact.
2 relays.
Surface mount.
Free voltage.
Installation with Torx
100 user codes.
Audible and visual feedback.
Dimensions (L x W x D): 140 x 80 x 20mm.
Input voltage:
- 12 V to 24V ac,
- 12 V to 48V dc.
Consumption: 40 to 100mA.
DEEE & RoHS
IP64
Certification CE
-25°C to +70°C
2] REMINDERS AND RECOMMENDATIONS
Recommended power supplies
- There are two suitable power supplies
for the encoded keypad:
ARD12 and BS60
- Separate power supply for control components.
Mounting recommendations
Mount the keypad on a flat surface to avoid
any vandalism and to insure the best mounting.
2
cdvigroup.com
screws.
®
Recommended
power supplies
ARD12 BS60
KCIEN
KCIENSBP
Security advice
For security advice reasons, change the factory
default master code. When selecting a master code
and user code avoid simple codes (example : 3 4 5 6 7).
Back EMF protection
To secure the system from back electromagnetic
fields do not forget to mount the varistor
in parallel on the lock.
