Replacing batteries

function is used. The door lock drive must be in idle status
(motor not moving) in this case.
Do not tighten the screws that fasten the door lock
drive to the mounting plate too tight, since it might
jam the drive and make opening from outside dif-
ficult.
8 Replacing batteries
If the symbol for empty batteries ( ) appears in the app,
replace the used batteries by three new 1.5 V LR6/ mi-
gnon/AA batteries. You must observe the correct battery
polarity.
To replace the batteries of the device, please proceed as
follows:
• Remove the battery compartment cover (E) on
the right side of the door lock drive (see figure 5)
by pulling the cover off using the notches at the
bottom of the device.
• Remove the used batteries.
• Insert three new 1.5 V LR6/mignon/AA batteries
into the compartment, making sure they are the
right way around. The device LED (C) LED shortly
flashes orange and the green. In addition, the de-
vice emits a short audio signal.
• Reattach the battery compartment cover and
