Mounting
ing the supplied Allen key in case it does not fit to
the cylinder lock of your door (see figure 9).
• Place the mounting plate onto the cylinder lock
(see figure 10).
• Tighten the screws (see figure 11).
Alternatively, the two screws supplied can be used
to screw the mounting plate to the door leaf (see
figure 11a).
• Insert the key into the cylinder lock.
• Select the position in which the key can be pulled
out and the lock is unlocked (see figure 12).
• Guide the device over the key and push it com-
pletely onto the mounting plate.
• Fasten the device using the two screws that were
screwed out in the beginning (see figure 13).
• In the app, define on which side of the door your
device is installed if you are looking at the door
from the inside.
• In the app, define in which position the key can
be pulled out.
• Also, define the number of turns that are
necessary in order to completely lock the door.
The device is fully mounted and the teach-in procedure is
completed in the app.
