Pan & Tilt Adjustments - Eneo IPB-73M2812MWA Schnellinstallationsanleitung

Assembly Screw: 4x15mm Assembly Screw: 4x15mm
Torque Wrench Torque Wrench
CAUTION:
Extreme care should be taken NOT to scratch the window in front
of lens.
Care should be taken the cable is NOT to be damaged, kinked or
exposed in the hazardous area.
Do not expose the camera directly to a strong light source such
as the sun or spot light.
Pan & Tilt adjustments Pan & Tilt adjustments
• Unlock the screw on the camera bracket through using the torque wrench supplied • Unlock the screw on the camera bracket through using the torque wrench supplied
• Set the camera's viewing angle then lock the screw on the bracket. • Set the camera's viewing angle then lock the screw on the bracket.
1. Pan limit: Pan is limited to +/- 90°. 1. Pan limit: Pan is limited to +/- 90°.
8
Mounting Screw 1: 4x30mm Mounting Screw 1: 4x30mm
4 4
CAUTION:
Extreme care should be taken NOT to scratch the window in front
of lens.
Care should be taken the cable is NOT to be damaged, kinked or
exposed in the hazardous area.
Do not expose the camera directly to a strong light source such
as the sun or spot light.
1
2 2
Easy bracket
3 3
Cable exit Cable exit
1
Easy bracket
