Log splitters with 230 and 400 volts
requires a minimum of 16 amperes
If any doubts please consult a qualified
electrician. Do not attempt any electrical
repairs yourself.

Making the log splitter ready

Picture 1. Remove the log splitter from its
packaging and lubricate the head.
Picture 2. Mount the wheels on the rod
with the flange facing inwards. Then
insert the locking pin.
Picture 3. Mount the arms on each side
and insert the locking-bolt. Secure these
with the locking pins.
Picture 4. Remove the oil-cap used
during transport and replace it with the
supplied oil-cap with the dipstick.
Picture 5. Attach the side-trays on both
sides.
Picture 6. Place the splitting-plate into the
bracket and fasten it with the bolt and
locking-nut.
Picture 7. When transporting the product,
use the supplied elastic band to fasten
the arms.
Picture 8. Unfold the arms to the sides, to
be able to place a log on the splitting-
plate.
Picture 9. Power on the product using the
power-inlet on the side and push the
green button. The product is now ready to
use.
When the safety button is pressed down,
the machine stops. Picture 10
Turning the phase (Only 400V)
If the engine powers on, but the piston
won't retract, the fault could be wrong
power phases. To turn it, use a
flatheaded screwdriver push it into the slit
and turn it 180 degrees. Picture 11

Starting and maintenance

Lubricate with some oil in the piston
tunnel on all 4 sides.
Lubrication shall be repeated after every
4 cubic meters.
Also remember to inspect the oil level in
the tank.

Oil

The oil level is checked by the means of
the oil dipstick.
The oil level has to be in between the two
marks.
Oil type for supplement: hydraulic oil.
Venting of hydraulic system
Vent the hydraulic system before putting
the log splitter into operation:
• Unscrew venting cap by several turns
so that air may escape from the oil
tank. See figure 4.
• Leave the cap open during operation.
• Close the venting cap before moving
the log splitter, as otherwise oil will
leak at this point.
Important: If the hydraulic system is not
vented, the trapped air will damage the
seals and cause permanent damage to
the log splitter!

Recommended hydraulic oil

We recommend the following oil to the
hydraulic cylinder: Texamatic 7045,
viscosity 33,8. Art. no. 90306479.
Or oil with corresponding viscosity
