EN
If the device is switched on but the water does not spray out:
• Make sure there are no foreign objects in the nozzle.
• Fill the tank with water.
• Turn on the device and carefully turn it upside down several times OR remove the nozzle, turn on the device and
pour water into the nozzle socket.
Use
• Insert the nozzle into your mouth towards your teeth and lean over the sink.
• Turn on the device.
• Hold the device vertically with the nozzle pointing up.
• Close your mouth so that the water does not spray out.
• Move smoothly along the teeth.
• A full tank lasts for approx. 45 seconds of use.
Modes
Normal - regular cleaning
Soft - gentle cleaning of teeth and gums
Pulse - effective removal of residues and plaque
To set the mode, press the power button. To stop the water flow, press the button for 5 seconds.
Nozzle types
Basic cleaning nozzle - removes residues and plaque
Nozzle for teeth with braces - cleans and rinses hard-to-reach areas around braces
Nozzle for cleaning the tongue - removes odours and keeps breath fresh, use "pulse" mode and gently run the nozzle
over the tongue
TROUBLE SHOOTING
Sonic electric toothbrush
Problem Possible cause
Too much pressure on teeth.
Weak vibrations
Improperly fitted brush head
Loose brush head or abnormal
The brush head is damaged
sound
Charging error.
Shorter operating time with
a charged battery
Empty battery
The toothbrush does not work
Power has run out
48
Remedy
Reduce pressure on teeth.
Fit the brush head again
Replace the brush head
Charge the toothbrush correctly.
Charge the brush to full charge
Charge the battery
ZK4030
Interdental cleaner
Problem Possible cause
End of battery life.
The device only works for a few
minutes (even after charging)
Insufficient charging time
Water pressure too low The nozzle is dirty/deformed
The device is too tilted during use
The water does not spray out There is dirt in the nozzle
The nozzle is incorrectly fitted
Newly purchased product or
The device does not work unused product for more than
three months

CLEANING AND MAINTENANCE

Sonic electric toothbrush
Brush head - After use, rinse with water and dry.
Brush body - Rinse with water and dry. Do not use water warmer than 40 °C or any cleaning agents.
Charging base - Wipe only with a dry cloth. Wet and damp fabrics can cause a short circuit.
Replacing the brush head - Dentists recommend replacing the brush head every 3 months.
Store the device in a dry and dust-free place.
Do not expose to high temperatures.
Keep out of reach of children.
Interdental cleaner
1. Pour water out of the tank.
• Switch on the device and let the remaining water drain out.
• If you have used a liquid other than water, wash the tank thoroughly. Then fill the tank with warm water, point
the nozzle at the sink and allow all the water to drain. This prevents clogging of the nozzle.
2. Press the nozzle release button, remove the nozzle and place it in the case.
3. Clean the device with a soft cloth or a mild, non-abrasive cleaning agent.
Nozzles
• Press the nozzle release button and remove the nozzle.
• Rinse with water and wipe dry.
• We recommend replacing the nozzle after 6 months. If the nozzle is deformed, replace it immediately.
Device body
• Wipe with a cloth and a mild detergent. Wipe dry.
• In case of heavy soiling, rinse with water. Then dry.
• Do not use water warmer than 50 °C.
ZK4030
EN
Remedy
Contact customer service
Charge the device in one go for more
than 16 hours
Replace the nozzle
see Preparation above
Charge the device for at least 10 hours
49
