EN
Control Panel Description
Button Function
<MENU> Exits from the current menu or function
<UP> Navigates upwards through the menu list and increases the numeric value when in a function
<DOWN> Navigates downwards through the menu list and decreases the numeric value when in a function
<ENTER> Enables the currently displayed menu or sets the currently selected value into the selected function
Menu Map
Refer for the Intimidator Scan 360 product page on
Main Function
Address
Run Mode
Manual
Setup
Sys Info
3
QUICK REFERENCE GUIDE
Programming Levels
001–512
DMX
Slave
Auto
Sound
IR
Pan
Tilt
Color
Gobo
Gobo Rotate
Prism
Focus
Dimmer
Strobe
Pan Reverse
Tilt Reverse
Screen Reverse
Signal Loss
Sensitivity
Indicator
Flash if DMX
Reset
Ver
Running Mode
DMX Address
Temperature
www.chauvetdj.com for the latest menu map.
Description
Sets the DMX starting address
8Ch
Selects DMX mode
12Ch
Sets unit to slave mode
Sets unit to Auto mode
Sets unit to Sound-active mode
Sets unit to infrared control mode
Controls pan settings
Controls tilt settings
Selects color options
Selects gobo options
000–255 Controls gobo rotation effects
Selects prism effects
Controls focus
Sets dimmer value
Controls strobe effects
OFF Normal pan operation
ON Reverse pan operation
OFF Normal tilt operation
ON Reverse tilt operation
OFF Normal display
ON Reverse display
Blackout Turns the unit off when DMX signal is lost
Hold Holds the last setting when DMX signal is lost
Auto Sets the unit to Auto mode when signal is lost
Sound Sets the unit to Sound mode when signal is lost
001–100 Sound sensitivity control
OFF
Turns indicator on or off
ON
OFF
LED Indicator flashes when DMX is turned ON or OFF
ON
Revert to factory settings
V_._ Displays software version
_ _ _ _ _ _ _ Displays current running mode
_ _ _ Displays current DMX mode
_ _ _ Displays the product temperature in Celsius
Intimidator Scan 360 QRG Rev. 2
